H6000i serials microscope
|
Items |
Spec and Parameter |
H6201i |
H6203i |
H6301i |
H6303i |
Order No. |
|
Eyepiece |
10X-18 |
●● |
●● |
●● |
●● |
EP10a |
|
IOS Plan Achromatic Objectives |
Plan 10X/0.25 |
|
● |
|
● |
B-OPi10a |
|
Plan 20X/0.40 |
|
● |
|
● |
B-OPi20a |
|
|
Plan 40X/0.66 |
|
● |
|
● |
B-OPi40a |
|
|
Plan 100X/1.25(Oil) |
|
● |
|
● |
B-OPoi100a |
|
|
IOS Achromatic Objectives |
4X/0.10 |
● |
|
● |
|
B-OAi4a |
|
10X/0.25 |
● |
|
● |
|
B-OAi10a |
|
|
40X/0.66 |
● |
|
● |
|
B-OAi40a |
|
|
100X/1.25(Oil) |
● |
|
● |
|
B-OAoi100a |
|
|
Eyepiece Heads |
Binocular Head (30°Inclined, Seidentopf) |
● |
● |
|
|
TBR11 |
|
Trinocular Head (30°Inclined, Seidentopf) |
|
|
● |
● |
TTR04 |
|
|
Main Body |
Worm and gear Focusing Mechanism、Quadplex Nosepiece |
● |
● |
● |
● |
A132b |
|
Mechanical Stage |
Moving Range:76x50、 Size: 160x135 |
● |
● |
● |
● |
S30 |
|
Condenser |
N.A. 1.25 |
● |
|
● |
|
C05 |
|
N.A. 1.25 |
|
● |
|
● |
C23 |
|
|
Condenser Focusing Team |
Rack and Pinion Focusing Mechanism |
● |
● |
● |
● |
CA03a |
|
Base |
Knob Switch、6V20W Halogen Tungsten Lamp |
● |
● |
● |
● |
B30 |
|
Immersion |
Knob Switch、6V20W Halogen Tungsten Lamp |
● |
● |
● |
● |
|
|
Filter |
Ø 32(Blue) |
● |
● |
● |
● |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
H6000i Series Optional Accessories
|
Items |
Spec. And Parameter |
Order No. |
|
|
Eyepieces |
10X-10 |
EW10 |
|
|
10X-18 (Pointer) |
Erg10 |
||
|
16X-10 |
EP16a |
||
|
16X-14 |
EW16 |
||
|
IOS Plan Achromatic Objectives |
Plan 4X/0.10 |
B-OPi4a |
|
|
Phase Contrast Attachment |
IOS Plan Positive Ph. Objectives |
Plan ph10/0.25 |
B-OPip10 |
|
Plan ph40/0.66 |
B-OPip40 |
||
|
Plan ph100/1.25(Oil) |
B-OPoip100 |
||
|
IOS Plan Negative Ph. Objectives |
Plan ph10/0.25 |
B-OPin10 |
|
|
Plan ph40/0.66 |
B-OPin40 |
||
|
Plan ph100/1.25 (Oil0 |
B-OPoin100 |
||
|
Phase Contrast Condenser |
C22 |
||
|
Centering Eyepiece |
ECi |
||
|
Main Body |
Worm and Gear Focusing Mechanism、 |
A13c |
|
|
Dark Field Attachment |
Dark Field Condenser (N.A. 0.83-0.91) |
C07 |
|
|
Polarizing Attachment |
Polarizer Slide |
PO01 |
|
|
Analyzer Slide |
PA01 |
||
|
Photo Attachment |
10X Reticle Eyepiece |
EPr10b |
|
|
2.5X Photo Eyepiece |
EPHn2.5 |
||
|
4X Photo Eyepiece |
EPHn4 |
||
|
6.3X Photo Eyepiece |
EPHn6.3 |
||
|
135 Photo Device (With 4x Photo Eyepiece) |
MP03 |
||
|
TV and Video Attachment |
C-mount Adaptor Color or Black and White Monitor CCD Camera |
TV02 |
|
|
Side Viewing Attachment |
Two View Field Space600mm |
TB06 |
|
|
Epi-illumination Attachment |
6V20W Halogen Tungsten Lamp (With Reflector) |
H09 |
|
|
Filter |
Ø 32 (Green、Amber) |
CU02-2、3 |
|
|
Image Analysis and Disposal System |
|
||
