Parts

Specification

Order No.

MIC-P202i

MIC-P203i

MIC-200i Frame

MIC-200i

●

●

Observation Tube

Binocular Tube, Interpupillary distance 52-75mm, 30°inclined. Diopter adjustment.

MSP2

●

Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined. Diopter adjustment.

MTP2

●

Eyepieces

WF10X/20mm, High eye-point up to 21mm.

E1020PA

●●

●●

Plan Polarizing Reticule Eyepiece10X/20mm.

EP1020RA

●

●

Objectives
"Strain-free"
Infinity
Plan

4X

WP-P4B

●

●

10X

WP-P10B

●

●

40X(S)

WP-P40B

●

●

60X(S)

WP-P60B

○

○

50X(S) (for reflected light)

WM-P50A

●

●

Polarizing

Condenser

Swing-out Condenser N.A.1.25 (centering adjustable)

JG50A

●

●

Stage

360°Rotating Stage

ZT7

●

●

Specimen Holder

ZT7-2000

●●

●●

Nosepiece

Quadruple Revolving Nosepiece

ZQP480

●

●

Intermediate Tube

PY10

●

●

Reflected Light Illuminator

Illuminator                                                                             Filter(Blue, Yellow, Green, 50% cutting filter)                      Analyzer slider & Polarizer slider

LS11

●

●

Compensator

1/4λ Retardation Plate

PBS137

●

●

λ Tint Plate

PBS530

●

●

Quartz Wedge

PBSQ

●

●

Kohler Illumination

With Field Diaphragm

KL3A

●

●

Electrical Parts

For 6V20W Halogen Lamp

DQ2

●

●

6V20W Osram Halogen Bulb

BZ-0022A

●

●

Reflected Light Lamp house

DX10

●

●

Power Supply Unit For Reflected Light Lamp house(12V/50W)

DYX2

●

●

12V50W Osram Halogen Bulb

BZ-0022D

●

●

250V/3.15AΦ5X20 Fuse

BZ-0023

●●●

●●●

C-Mount

0.5X

SX2

●

Filter

Blue (Φ38 )

LA5-0011

●

●

Immersion Oil

BZ-0027

●

●

Dust Cover

BZ2-0014

●

●

Allen Screw Driver

Φ2mm

BZ2-0018

●

●

Φ1.5mm

BZ3-0018

●●

●●

Power Cord

BZ-0021

●

●

Package

●

●
