Items |
Spec and Parameter |
BA2203i |
BA2303i |
BA2305i |
Order No. |
||
|
Eyepiece |
WF 10X- Ø 20 |
●● |
●● |
●● |
EW10 |
||
|
Objectives |
ISO Plan Achromatic Objectives 10X/0.25 |
● |
● |
|
B-OPi10a |
||
|
ISO Plan Achromatic Objectives 20X/0.40 |
● |
● |
|
B-OPi20a |
|||
|
ISO Plan Achromatic Objectives 40X/0.66 |
● |
● |
|
B-OPi40a |
|||
|
ISO Plan Achromatic Objectives 100X/1.25(Oil) |
● |
● |
|
B-OPoi100a |
|||
|
ISO Plan Fluorescent Objectives10X/0.3 |
|
|
● |
|
|||
|
ISO Plan Fluorescent Objectives25X/0.65 |
|
|
● |
|
|||
|
ISO Plan Fluorescent Objectives40X/0.85 |
|
|
● |
|
|||
|
ISO Plan Fluorescent Objectives100X/1.25 (oil) |
|
|
● |
|
|||
|
Main Body |
|
Quintuple Nosepiece |
● |
● |
|
A08a |
|
|
Seidentopf Binocular Head |
|
|
● |
|
|
TBR11 |
|
|
Seidentopf Trinocular Head |
|
|
|
● |
● |
TTR04 |
|
|
Mechanical Stage |
|
Moving Range: 76×50 Size: 160×135 |
● |
● |
|
S26 |
|
|
Condenser Focusing Team |
|
Rack and Pinion Focusing Mechanism |
● |
● |
|
CA03a |
|
|
Condenser |
|
N.A. 1.25 |
|
|
|
C23 |
|
|
Field Diaphragm |
Ø 2-ø35 |
● |
● |
|
DI06 |
||
|
Immersion Oil |
|
● |
● |
|
|
||
|
Filter |
Ø 32 (Blue) |
● |
● |
|
CU2-1 |
||
|
Epi-fluresent illumination system (V, UV, B, G), 100W AC mercury lamp house, 100W AC mercury power house (order number: FD06+LH08+PS-2) |
● |
|
|||||
BA2000i Series
Optional Accessories
|
Items |
Spec and Parameter |
Order No. |
|
|
Eyepieces |
10X-18 (Pointer) |
Erg10 |
|
|
16X-10 |
EP16a |
||
|
16X-14 |
EW16 |
||
|
IOS Plan Achromatic Objective |
Plan 4X/0.10 |
B-OPi4a |
|
|
Phase Contrast Attachment |
IOS Plan Positive Ph. Objectives |
Plan ph10x/0.25 |
B-OPip10a |
|
Plan ph20x/0.40 |
B-OPip20a |
||
|
Plan ph40x/0.66 |
B-OPip40a |
||
|
Plan ph100x/1.25(Oil) |
B-OPoip100a |
||
|
IOS Plan Negative Ph. Objectives |
Plan ph10x/0.25 |
B-OPin10 |
|
|
Plan ph20x/0.40 |
B-OPin20 |
||
|
Plan ph40x/0.66 |
B-OPin40 |
||
|
Plan ph100x/1.25(Oil) |
B-Opoin100 |
||
|
Phase Contrast Condenser |
C22 |
||
|
Centering Eyepiece |
ECi |
||
|
Dark Field Attachment |
Dark Field Condenser (N.A. 0.83-0.91) |
C07 |
|
|
Polarizing Attachment |
Polarizer Slide |
PO01 |
|
|
Analyzer Slide |
PA01 |
||
|
Photo Attachment |
10X Reticle Eyepiece |
EPr10b |
|
|
2.5X Photo Eyepiece |
EPHn2.5 |
||
|
4X Photo Eyepiece |
EPHn4 |
||
|
6.3X Photo Eyepiece |
EPHn6.3 |
||
|
135 Photo Device (With 4x Photo Eyepiece) |
MP03 |
||
|
TV and Video Attachment |
C-mount Adaptor、Color or Black and White Monitor、CCD Camera |
TV02 |
|
|
Epi-illumination Attachment |
6V20W Halogen Tungsten Lamp (With Reflector) |
H09 |
|
|
Side Viewing Attachment |
Two View Field Space600mm |
TB06 |
|
|
Projection Attachment |
|
PJ04 |
|
|
Filter |
Ø 32 (Green、Amber) |
CU02-2、3 |
|
|
Image Analysis and Disposal System |
|
|
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make
design modification and changes without notice.
