Main parameters |
Total magnification |
100X (standard configure) |
||||
|
Mechanical tube length |
∞ |
|||||
|
Conjugate distance of objective |
∞ |
|||||
|
Eyepiece |
Wide-field plan eyepiece |
WF 10X |
field
of view number |
Eyepiece interface Ф23.2mm |
Parfocal distance 10mm |
|
|
Trinocular |
Observation angle of 30° with photography port，spectro rate 8：2（eyepiece：photography） |
|||||
|
Strain-free plan achromatic objective |
Magnification |
Numerical aperture |
Working distance (mm) |
Thickness of cover glass (mm) |
Remarks |
|
|
10X |
0.25 |
20.2 |
- |
|
||
|
Analyzer |
Insert type，can be switch freely，the direction of polarization has preset, no use for adjust |
|||||
|
Polarizer |
Insert type，can be switch freely，360°rotatable |
|||||
|
DIC Slider |
DIC slider matching 5X/10X/20X objective，horizontal adjustable |
|||||
|
X-Y Stage |
double layer mechanism stage， size：180 X145mm，moving range：35X30 mm（X-Y） |
|||||
|
Vertical availability distance |
Focus system available distance133mm, observational specimen maximal thickness up to130mm. |
|||||
|
focus system |
Coaxial coarse/fine focus system, minimum division of fine focusing: 2μm |
|||||
|
Illumination |
Coaxial illumination using high brightness white LED. Brightness adjustable |
|||||
|
Main power sullpy |
AC:85V~265V 50/60Hz，fuse specification：250V3.0A |
|||||
|
Accessory (optional) |
Objective |
20X strain-free plan achromatic objective，NA：0.40，working distance：8.0mm |
||||
|
Digital camera |
130、300、500、1000mega pixels，with image analysis software. |
|||||
|
|
||||||
