Items |
IBE1000 |
Order No. |
|
10× WF eyepiece FN＝20 |
●● |
EW10 |
|
16× WF eyepiece FN＝14 |
●● |
EW16 |
|
10× plan reticle eyepiece FN＝18 |
● |
EPr10b |
|
Centering eyepiece |
● |
ECi |
|
2.5× long working distance objective NA＝0.07; WD =28.89 |
○ |
B-OLPr2.5 |
|
4× long working distance objective NA＝0.10 ;WD=16.50 |
○ |
B-OLPr4 |
|
10× long working distance objective NA＝0.25; WD=7.90 |
● |
B-OLPr10 |
|
25× long working distance objective NA＝0.40; WD=5.00 |
● |
B-OLPr25 |
|
40× long working distance objective NA＝0.65; WD=3.00 |
● |
B-OLPr40 |
|
10× long working distance positive phase contrast objective NA＝0.25 ; WD=7.90 |
● |
B-OLPpr10 |
|
25× long working distance positive phase contrast objective NA＝0.40 ;WD=5.00 |
● |
B-OLPpr25 |
|
40× long working distance positive phase contrast objective NA＝0.65 ;WD=3.00 |
● |
B-OLPpr40 |
|
10× long working distance negative phase contrast objective NA＝0.25 ;WD=7.90 |
○ |
B-OLPnr10 |
|
25× long working distance negative phase contrast objective NA＝0.40 ; WD=5.00 |
○ |
B-OLPnr25 |
|
40× long working distance negative phase contrast objective NA＝0.65 ;WD=3.00 |
○ |
B-OLPnr40 |
|
long working distance phase contrast condenser NA＝0.30;WD=55.00 |
● |
C15 |
|
Mechanical stage: size:238×160; moving range: 50×50 |
● |
S28 |
|
Sliding trinocular head, Inclined 45°, Interpupilary Distance: 55-75mm |
● |
18X.30 |
|
Photography tube group |
○ |
MP04 |
|
Photography adaptor |
○ |
TV04 |
|
Digital Photography device (CU43-2+DV02+camera) |
○ |
|
|
0.01mm micrometer |
○ |
|
