MIC-C series USB2.0 (buffer) cameras adopt image buffer and large area array CMOS sensor, with features as: reliable and stable transmission, high resolution, high definition, low noise,excellent color reproduction etc. Plug and play USB2.0 interface.
|
Model No |
Sensor |
Sensor |
Color |
Sensor |
Pixel |
Shutter |
Pixel |
Resolution |
Data |
Frame |
Lens |
|
C036 |
CMOS |
MT9V032 |
Color |
1/3” |
6.0μm |
Global |
0.36MP |
752 x 480 |
USB2.0 |
114FPS |
C/ CS |
|
C036M |
CMOS |
MT9V032 |
Mono |
1/3” |
6.0μm |
Global |
0.36MP |
752 x 480 |
USB2.0 |
114FPS |
C/ CS |
|
C130M |
CMOS |
MT9M001 |
Mono |
1/2” |
5.2μm |
Rolling |
1.3MP |
1280 x 1024 |
USB2.0 |
30FPS |
C/ CS |
|
C300 |
CMOS |
MT9T001 |
Color |
1/2” |
3.2μm |
Rolling |
3MP |
2048 × 1536 |
USB2.0 |
12FPS |
C/ CS |
|
C500M |
CMOS |
MT9P031 |
Mono |
1/2.5” |
5.2μm |
Rolling |
5MP |
2592 x 1944 |
USB2.0 |
9FPS |
C/ CS |
|
C501 |
CMOS |
MT9P006 |
Color |
1/2.5” |
2.2μm |
Rolling |
5MP |
2592 × 1944 |
USB2.0 |
9FPS |
C/ CS |
|
C1000 |
CMOS |
MT9J003 |
Color |
1/2.3” |
1.67μm |
Rolling |
10MP |
3664 × 2748 |
USB2.0 |
4FPS |
C/ CS |
|
Model |
C036-H |
|
Sensor Size |
1/3" CMOS Color |
|
Effective Pixels |
752×480(0.36M) |
|
Resolution/ |
752×480: 114FPS |
|
640×480:124FPS |
|
|
320×240:228FPS |
|
|
Pixel Size |
6.0μm×6.0μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter type |
Global Shutter |
|
Exposure Time |
0.01~300ms |
|
Image Data Format |
Raw8/Raw10 |
|
Sensitivity |
4.8V/Lux-sec(550nm) |
|
SNR |
37.3 dB |
|
Dynamic Range |
55 dB |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Area |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Programmable Control |
Image Size,Photograph Mode,Exposure Time,Gain, |
|
Operating System |
Windows XP(32 bit/64 bit） / Windows7(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Lens Mount |
C/ CS Mount |
|
PCB Size |
39×39mm(2 boards) |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
|
Model |
C036M-H |
|
Sensor Model |
MT9V032 |
|
Sensor Size |
1/3" CMOS Monochrome |
|
Effective Pixels |
752x480(0.36M) |
|
Resolution/ |
752x480:114FPS |
|
640x480(ROI):124FPS |
|
|
320x240(ROI):228FPS |
|
|
Any Area（ROI） |
|
|
Pixel Size |
6.0μmx6.0μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter Type |
Global Shutter |
|
Exposure Time |
0.029-300ms |
|
Image Data Format |
Mono8/Mono10 optional |
|
Sensitivity |
4.8V/Lux-sec(550nm) |
|
Spectral Response |
380nm-1050nm |
|
SNR |
37.3 dB |
|
Dynamic Range |
>55 dB |
|
Exposure |
Manual / Auto / Area |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Picture Format |
JPG / BMP / PNG / RAW |
|
programmable control |
Camera Operating Speed,Image Size,Photograph Mode,Exposure Time,Gain,Stroboscopic Elimination, |
|
Operating System |
Windows XP(32 bit） / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Rated Power |
＜ 1.5W |
|
Rotated Voltage |
USB5V Power Supply（No external power supply circuit） |
|
Temperature |
Working ：0～50℃ / Storage：-20℃～60℃ |
|
Humidity |
Workimg：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
Lens Mount |
C/ CS Mount |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
|
Model |
C130M-H |
|
Sensor Size |
1/2" CMOS Monochrome |
|
Effective Pixels |
1280x1024(1.3M) |
|
Resolution/ |
1280×1024:30FPS |
|
1024×768(ROI):38.7FPS |
|
|
640×480(ROI):55FPS |
|
|
320×256(ROI):93FPS |
|
|
Any Area（ROI） |
|
|
Pixel Size |
5.2μm×5.2μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter Type |
Rolling Shutter |
|
Exposure Time |
0.01~300ms |
|
Image Data Format |
Mono8/Mono10 optional |
|
Sensitivity |
2.1V/Lux-sec |
|
SNR |
45 dB |
|
Dynamic Range |
68.2 dB |
|
Definition |
800 Line |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
None |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Programmable Control |
Image Size,Photograph Mode,Exposure Time,Gain, |
|
Operating System |
Windows XP(32 bit/64 bit） / Windows7(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Rated Power |
＜ 1.5W When Working,Approx. 0.9W When Standby |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Lens Mount |
C/ CS Mount |
|
PCB Size |
39×39mm(2 boards) |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
|
Model |
C300-H |
|
Sensor Size |
1/2" CMOS Color |
|
Effective Pixels |
2048×1536(3M) |
|
Resolution/ |
2048×1536:12FPS |
|
1920×1080(ROI):18FPS |
|
|
1024×768(ROI):43FPS |
|
|
1024×768(BIN):38FPS |
|
|
640×480(ROI):83FPS |
|
|
Any Area（ROI） |
|
|
Pixel Size |
3.2μm×3.2μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter Type |
Rolling Shutter |
|
Exposure Time |
0.02~300ms |
|
Image Data Format |
Raw8/Raw10/Raw12 |
|
Sensitivity |
>1.0V/Lux-sec(550nm) |
|
SNR |
43 dB |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-time / Area |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Programmable Control |
Image Size,Photograph Mode,Exposure Time,Gain,GAMMA , Contrast , RGB Gain, Saturation, Sharpness, Software Noise Reduction |
|
Operating System |
Windows XP(32 bit/64 bit） / Windows7(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Lens Mount |
C/ CS Mount |
|
PCB Size |
39×39mm(2 boards) |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
|
Model |
C500M-H |
|
Sensor Size |
1/2.5" CMOS Monochrome |
|
Effective Pixels |
2592×1944（5M） |
|
Resolution/ |
2592×1944：9FPS |
|
2048×1536：14FPS |
|
|
1920×1080：22FPS |
|
|
1280×960：36 FPS |
|
|
640×480：55 FPS |
|
|
Any Area（ROI） |
|
|
Pixel Size |
5.2μm×5.2μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter Type |
Rolling Shutter |
|
exposure time |
0.036~300ms |
|
Image Data Format |
Mono8/Mono10 optional |
|
Sensitivity |
2.1V/Lux-sec |
|
SNR |
45 dB |
|
Dynamic Range |
68.2 dB |
|
Definition |
1100-1200 Line |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
None |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Programmable Control |
Image Size,Photograph Mode,Exposure Time,Gain, |
|
Operating System |
Windows XP(32 bit/64 bit） / Windows7(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Rated Power |
＜ 1.5W When Working,Approx. 0.5W When Standby |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Lens Mount |
C/ CS Mount |
|
PCB Size |
39×39mm(2 boards) |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
|
Model |
C501-H |
|
Sensor Size |
1/2.5" CMOS Color |
|
Effective Pixels |
2592×1944（5M） |
|
Resolution/ |
2592×1944：9FPS |
|
2048×1536（ROI）：14 FPS |
|
|
1920×1080（ROI）：22 FPS |
|
|
1280×960（SUM）：36 FPS |
|
|
1280×960（BIN）：36 FPS, 640×480（SUM）：55 FPS |
|
|
640×480（BIN）：55 FPS |
|
|
Any Area ROI |
|
|
Pixel Size |
2.2μm×2.2μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter Type |
Rolling Shutter |
|
Exposure Time |
0.036~300ms |
|
Image Data Format |
Raw8/Raw10/Raw12 |
|
Sensitivity |
1.76V/Lux-sec(550nm) |
|
SNR |
38.5 dB |
|
Dynamic Range |
67.7 dB |
|
Definition |
1100-1200 Line |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Area |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Programmable Control |
Image Size,Photograph Mode,Exposure Time,Gain, |
|
Operating System |
Windows XP(32 bit/64 bit） / Windows7(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Lens Mount |
C/ CS Mount |
|
PCB Size |
39×39mm(2 boards) |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
|
Model |
C1000-H |
|
Sensor Size |
1/2.3" CMOS Color |
|
Effective Pixels |
3664×2748(10M) |
|
Resolution/ |
3664×2748 4FPS |
|
1832×1374: 16FPS |
|
|
1920×1080: 20FPS |
|
|
1280×720: 42FPS |
|
|
916×688: 43FPS |
|
|
Any Area ROI |
|
|
Pixel Size |
1.67μm×1.67μm |
|
Scanning Mode |
Progressive Scan |
|
Shutter Type |
Rolling Shutter |
|
Exposure Time |
0.05~300ms |
|
Image Data Format |
Raw8/Raw10/Raw12 |
|
Sensitivity |
0.31V/Lux-sec(550nm) |
|
SNR |
34 dB |
|
Dynamic Range |
65.2 dB |
|
Definition |
1500 Line |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Area |
|
Product firmware update |
Support Remote Update |
|
Product ID |
User Defined |
|
Programmable Control |
Image Size,Photograph Mode,Exposure Time,Gain, |
|
Operating System |
Windows XP(32 bit/64 bit） / Windows7(32 bit/64 bit) |
|
Software Interface |
DirectShow / TWAIN |
|
Data Interface |
USB2.0 480Mb/s |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Rated Power |
＜ 1.5W When Working,Approx. 0.5W When Standby |
|
Working Temperature |
0～50℃ |
|
Working Humidity |
10%～90%RH（No condensation） |
|
Lens Mount |
C/ CS Mount |
|
PCB Size |
39×39mm(2 boards) |
|
Dimension |
44mm x 44mm x 39mm （Exclude Extended Ring and External Firmware Block） |
|
Weight |
Approx. 121g |
