MIC-GM serials cmos digital video eyepiece
0.1MP pixel cmos digital video eyepiece
To equip 0.10MP color CMOS sensor, and to operate at normal PC without high specifications, the resolution of 320*240 is suitable for determining the nature of sample by viewing, recording and analyzing, it is a primary model.
Feature
|
Power supply |
USB port |
|
Tube diameter |
23.2 mm or30.0mm |
|
Connection |
Ocular tube or C-mount |
|
uniform focusing |
YES |
|
Optical magnification |
10X |
|
Rate of field |
1/3 |
|
Matching lens |
YES |
|
Function of software |
Image file management：set up, open up, save, lead in image file Image capture: switch, setting, shoot, measure, full screen view. Image edit: picture turn, zoom, cut, modify, email, print |
|
Resolution of display |
320*240 |
|
Resolution of picture |
320*240 |
|
Resolution of video |
320*240 |
|
USB cable |
1.5 m |
|
Weight of device |
0.11kg |
Specifications
|
Sensor Parameter |
1/7" 0.1MP CMOS |
|
Resolution |
320*240 |
|
USB port |
USB 1.1 |
|
Frame Rate |
24 fps @320x240 |
|
Preview Model |
320*240 |
|
Pixel Size |
5.6μm *5.6μm |
|
Sensitivity |
190 level/ lux-sec (550nm) |
|
Dynamic Range |
31.6 db (Max) |
|
White balance |
Auto |
|
O/P compatibility |
Win2k,WinXP,Vista |
|
Packing |
1. Single box: Weight:0.2kg, Measurement: 15.5*13.5*7.0㎝³; 2. One carton of 50 PCS: Weight:11.0 kg, Measurement: 65.0*33.5*36.5㎝³; |
0.35M pixel cmos digital video eyepiece
To equip 0.35MP sensor and offer rate of 30 frames per second at resolution of 640*480, it is an idea model to track character of live specimen or movable target by taking video. MSR350 is a general and popular model and is of wide use in production controlling.
Features
|
Power supply |
USB port |
|
Tube diameter |
23.2 mm or30.0mm |
|
Connection |
Ocular tube or C-mount |
|
Uniform focusing |
YES |
|
Optical magnification |
10X |
|
Rate of field |
1/3 |
|
Matching lens |
YES |
|
Function of software |
Image file management：set up, open up, save, lead in image file Image capture: switch, setting, shoot, measure, full screen view. Image edit: picture turn, zoom, cut, modify, email, print |
|
Resolution of display |
640*480 |
|
Resolution of picture |
640*480 |
|
Resolution of video |
640*480 |
|
USB cable |
1.5m |
|
Weight of device |
0.071kg |
Specifications
|
Sensor Parameter |
1/4" 0.35MP CMOS |
|
Resolution |
640*480 |
|
USB port |
USB 2.0 |
|
Frame Rate |
30 fps @640*480 |
|
Preview Model |
640*480, 320*240 |
|
Pixel Size |
5.6μm *5.6μm |
|
Sensitivity |
1.9 V/lux-sec |
|
Dynamic Range |
RGB Bayer Pattern |
|
White balance |
AUTO |
|
O/P compatibility |
Win2k,WinXP,Vista |
|
Packing |
1. Single box: Weight:0.25kg, Measurement: 15.5*13.5*7.0 ㎝³; 2. One carton of 50 PCS: Weight:15.40 kg, Measurement: 69.0*33.5*36.5㎝³; |
1.3M pixel cmos digital video eyepiece
To equip 1.3 MP CMOS sensor and offer full screen display of 1280*1024 inresolution, to equip professional matching optical system and insure sharp and true color images, to equip advanced IC board and have the picture be of wide dynamic range, rich gray tone, it is available to fit on any kinds of precise and compact microscope stably for its compact structure.
Feature
|
Power supply |
USB port |
|
Tube diameter |
23.2 mm or30.0mm |
|
Connection |
Ocular tube or C-mount |
|
Uniform focusing |
YES |
|
Optical magnification |
10X |
|
Rate of field |
1/3 |
|
Matching lens |
YES |
|
Function of software |
Image file management：set up, open up, save, lead in image file Image capture: switch, setting, shoot, measure, full screen view. Image edit: picture turn, zoom, cut, modify, email, print |
|
Resolution of display |
1280*1024 |
|
Resolution of picture |
1280*1024 |
|
Resolution of video |
1280*1024 |
|
USB cable |
1.5m |
|
Weight of device |
0.10㎏ |
Specifications
|
Sensor Parameter |
1/3" 1.3MP CMOS |
|
Resolution |
1280*1024 |
|
USB port |
USB 2.0 |
|
Frame Rate |
16 fps @ 1280*1024 |
|
Preview Model |
1280*1024, 640*480, 320*240 |
|
Pixel Size |
3.6μm *3.6μm |
|
Sensitivity |
1.0 V/lux-sec@550nm |
|
Spectrum response |
400nm-1000nm |
|
Shutter Type |
ERS(electronic rolling shutter) |
|
White Balance |
AUTO |
|
The Length of USB |
1.5m |
|
O/P compatibility |
Win2k,WinXP,Vista |
|
Packing |
1. Single box:Weight:0.32kg,Measurement: 19.0*13.5*8.5 ㎝³; 2. One carton of 50 PCS: Weight:17.0 kg, Measurement: 68.0*40.0*45.0㎝³; |
3M pixel cmos digital video eyepiece
To equip 3.0 MP CMOS sensor and offer an extra digital zoom function for low optical magnification microscope, to equip professional matching optical system and insure sharp and true color images, it is available to fit on any kinds of precise and compact microscope stably for its compact structure.
Feature
|
Power supply |
USB port |
|
Tube diameter |
23.2 mm or30.0mm |
|
Connection |
Ocular tube or C-mount |
|
Uniform focusing |
YES |
|
Optical magnification |
10X |
|
Rate of field |
1/2 |
|
Matching lens |
YES |
|
Function of software |
Image file management：set up, open up, save, lead in image file Image capture: switch, setting, shoot, measure, full screen view. Image edit: picture turn, zoom, cut, modify, email, print |
|
Resolution of display |
2048*1536 |
|
Resolution of picture |
2048*1536 |
|
Resolution of video |
2048*1536 |
|
USB cable |
1.5m |
|
Weight of device |
0.10㎏ |
Specifications
|
Sensor Parameter |
1/2" 3.0MP CMOS |
|
Resolution |
2048*1536 |
|
USB port |
USB 2.0 |
|
Frame Rate |
7.5 fps@ 2048*1536 |
|
Preview Model |
2048*1536,1280×1024 ,1024×768 |
|
Pixel Size |
3.18μm *3.18μm |
|
Sensitivity |
1.0 V/lus-secx @550nm |
|
S/N Ratio |
40 dB |
|
Dynamixc Range |
60dB |
|
Color Filter |
RGB Bayer Pattern |
|
White Balance |
AUTO |
|
USB Cable Length |
1.5m |
|
O/P compatibility |
Win2k,WinXP,Vista |
|
Packing |
1. Single box:Weight:0.32kg,Measurement: 19.0*13.5*8.5 ㎝³; 2. One carton of 50 PCS: Weight:17.0 kg, Measurement: 68.0*40.0*45.0㎝³;
|
5M pixel cmos digital video eyepiece
To equip 5.0 MP CMOS sensor and offer enough digital zoom aid for inspecting detailed message of fine specimen when the software attached to capture live image and video in top resolution of 2560*1944, to equip professional matching optical system and insure sharp and true color images, it is available to fit on any kinds of precise and compact microscope stably for its compact structure.
Feature
|
Power supply |
USB port |
|
Tube diameter |
23.20 mm or30.00mm |
|
Connection |
Ocular tube or C-mount |
|
Uniform focusing |
YES |
|
Optical magnification |
10X |
|
Rate of field |
1/3 |
|
Matching lens |
YES |
|
Function of software |
Image file management: set up, open up, save, lead in image file Image capture: switch, setting, shoot, measure, full screen view. Image edit: picture turn, zoom, cut, modify, email, print |
|
Resolution of display |
2560*1944 |
|
Resolution of picture |
2560*1944 |
|
Resolution of video |
2560*1944 |
|
USB cable |
1.5m |
|
Weight of device |
0.10㎏ |
Specifications
|
Sensor Parameter |
1/2.5" 5.0MP CMOS |
|
Resolution |
2592*1944 |
|
USB Port |
USB 2.0 |
|
Frame Rate |
3.75 fps for 2560*1944 |
|
Pixel Size |
2.2μm *2.2μm |
|
Sensitivity |
1.4 V/Lux-sa(550nm) |
|
Color Filter |
RGB Bayer Pattern |
|
White Balance |
AUTO |
|
USB Cable Legth |
1.5m |
|
O/P compatibility |
Win2k,WinXP,Vista |
|
Packing |
1. Single box:Weight:0.32kg,Measurement: 19.0*13.5*8.5 ㎝³; 2. One carton of 50 PCS: Weight:17.0 kg, Measurement: 68.0*40.0*45.0㎝³; |
