This serials microscope is developed for various applied scopes. From daily work to scientific research, it is widely used in Biology, Histology, Pathology, Medicament chemistry research and Clinical examination. It is also used foreducationCollegesand Schools.
|
Specification |
XSP-N18F |
XSP- N18H |
XSP- N18T |
|||
|
Viewing head |
Monocular head inclined at 45 ° |
● |
|
|
||
|
Compensation Free Binocular Head. Inclined at 3 0 ° (55mm-75mm) |
|
● |
|
|||
|
Compensation Free Trinocular Head. Inclined at 3 0 ° (55mm-75mm) |
|
|
● |
|||
|
Eyepiece |
WF10 × |
● |
● |
● |
||
|
Objective |
Achromatic objective: 4 × ,10 × ,40 × (S),100 × (S)Oil |
● |
● |
● |
||
|
Stage |
Double layers mechanical stage |
● |
● |
● |
||
|
Stage size:140mm×140mm |
● |
● |
● |
|||
|
Moving range:75mm×50mm |
● |
● |
● |
|||
|
Condenser |
N.A1.25 Abbe condenser with iris diaphragm & filter |
● |
● |
● |
||
|
Focusing |
Coaxial coarse & fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
● |
||
|
Collector |
High brightness collector and can be interconvert with Kohler illumination |
● |
● |
● |
||
|
Light source |
Halogen tungsten bulb 6V/30W.AC 85V-230V |
● |
● |
● |
||
|
Adjustable brightness |
||||||
|
Optional Accessory |
Eyepieces: |
WF16x,WF20x, P16x 1.3 Mega pixels CMOS electronic eyepiece . |
||||
|
Semi-plan objectives: |
4X,10X,20X(S),40(S),60X(S),100(S)Oil |
Photo and CDD attachment |
||||
|
|
|
|||||
