Specification |
Model |
|
|
XSZ-11P |
||
|
Viewing head |
Sliding Binocular Head. Inclined at 45 ° (52mm-74mm) |
● |
|
Eyepiece |
WF10 × /18mm |
● |
|
10 × gridding eyepiece |
● |
|
|
10 × with reticule |
● |
|
|
WF10 ×22mm |
|
|
|
Objective |
Achromatic objective: 4 × ,10 × ,25 × , 40 × (S),63 × (S) |
● |
|
Stage |
Round revolving stage |
● |
|
Stage dia: Φ160mm |
||
|
Rotatable: 360 ° |
||
|
Condenser |
Swing type N.A1.25 Abbe condenser with iris diaphragm & filter |
● |
|
Focusing |
Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value 0.002mm |
● |
|
Collector |
High brightness light collector |
● |
|
Light source |
Halogen tungsten bulb 6V/30W.AC 85V-230V |
● |
|
Adjustable brightness |
● |
|
|
Optional Accessory |
Eyepieces: WF16x,WF20x,P16x 1.3Mega、3.0Mega Pixels CMOS Digital camera eyepiece |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have
reserved the right to
make design modification and changes without notice.
