Eyepiece |
WF10x/Ø18 |
●● |
EP10g |
|
WF10x/Ø18 (reticle) |
● |
Epr10b |
|
|
Objectives
|
Infinite Achromatic Objectives 4x/0.1 Stressless |
● |
B-OAi4b |
|
Infinite Achromatic Objectives 10x/0.25 Stressless |
● |
B-OAi10b |
|
|
Infinite Achromatic Objectives 40x/0.65 Stressless |
● |
B-OAi40b |
|
|
Infinite Achromatic Objectives 100x/1.25 (oil) Stressless |
● |
B-OAoi100b |
|
|
Main body |
Quadruple Nosepiece (center adjustable) Coaxial Coarse and Fine Focusing Knobs (fine knob0.002mm) Stage 360° Rotatable with fixing thumb screw, Lattice-valued: 1°, precision:6’ |
● |
A14b |
Head |
Seidentopf Binocular Head (or trinocular) Inclined 30°, Rotatable 360° Interpupilary Distance: 52-75mm Middle Drawtube Middle drawtube: movable optical path,with inner fixed polarizer with changeable polarizing direction, 100°rotatable，cursor lattice 6′, with Bertrand lens switch turntable; withλ/4 wave plate,λ wave plate and quartz fid (Ⅰ-Ⅳ) |
● |
TBR20 |
|
Polarizer |
With fixing device and movable optical path |
● |
C32 |
|
Collector |
|
● |
COL03 |
|
Base |
Bulb: Halogen Tungsten Lamp 6V20W, Fuse: Ø5X20/2A, Input voltage: AC85V-265V, 50HZ/60HZ, Output voltage: DC1.4V-6V Maximum output power 20W |
● |
B32 |
|
|
0.01 Micrometer |
|
|
|
|
Moving Scaling |
|
|
