Items

Specification

OP-4

Eyepiece

WF 10×-18mm

●

WF 10×-18mm(Reticule0.1mm)

●

Non-stress
Infinity
Plan Objective

4×

●

10×

●

20× (S)

●

40× (S)

●

60× (S)

○

Seidentopf Binocular Head

Inclined 30°, Rotatable 360°,
Interpupilary Distance:  50-75mm.

●

Seidentopf Trinocular Head

Inclined 30°, Rotatable 360°,
Interpupilary Distance:  50-75mm.
Light Distribution: 20:80

○

Nosepiece

Quadplex, Center adjustable

●

Analyzer Unit with Scale

Rotatable 360°(Module Type, Can Be Locked)

●

Bertrand Lens

Inbuilt, Center Adjustable

●

λ Slip

First Class Red

●

1/4λSlip

●

Quartz Wedge

(Ⅰ-Ⅳ Class)

●

Revolving Round Stage

Rotatable 360°, Center Adjustable, Division 1°,

Vernier division6’

●

Polarizing Attached Mechanical Stage

○

Condenser

Abbe N.A. 1.25      Non-stress

●

Polarizing Unit with Scale

Rotatable 360°,Can Be Locked

●

Illumination

6V/20W Halogen Lamp

●

6V/30W Halogen Lamp

○

Filter

Blue(Built in)

●

Amber

○

Green

○

Neutral

○

C-mount

1X, 0.47X （Focus adjustable）

○
