3M pixel CMOS camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
AR0330 CMOS sensor(Color) |
|
|
Scan Mode |
Progressive |
|
|
Max.Resolution |
2048 x 1534 (Approx. 3,140,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/3“ (Diagonal6.0mm) |
|
|
Pixel Size |
2.2µm x 2.2µm |
|
|
Imaging Area |
4.505mm(H) x3.375mm(V) |
|
|
Dynamic Range |
72.4dB |
|
|
A/D Converter |
12-bit on board, 8-bit R-G-B processed |
|
|
SN Ratio |
39dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Responsivity |
2.0V/lux-sec |
|
|
Video Format & Max.Frame Rate |
27.4fps @2048 x 1534, 53.3fps @1024 x 770 (Multiple Speed Level) |
|
|
Binning |
1 x 1, 2 x 2 |
|
|
Output Rate |
98MBytes/s |
|
|
Exposure |
0.1ms~2000ms, ROI Auto & Manual |
|
|
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
|
Capture/Control API |
Native C/C++, .Net/C#, DirectShow, Twain |
|
|
Peak Quantum Efficiency |
N/A |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Recording System |
Still Picture and Movie |
|
|
Cooling System* |
Nature |
|
|
OPERATING ENVIRONMENT |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
|
Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory: 2GB or more |
||
|
USB port: USB3.0 High-speed Port |
||
|
Display: 17" or larger |
||
|
CD-ROM |
||
5M pixel CMOS camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
MT9P006 CMOS sensor(Color) |
|
|
Scan Mode |
Progressive |
|
|
Max.Resolution |
2560 x1922 (Approx. 5,000,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/2.5“ (5.7mm(H) x4.28mm(V), Diagonal7.13mm) |
|
|
Pixel Size |
2.2µm x 2.2µm |
|
|
Imaging Area |
5.632mm(H) x4.228mm(V) |
|
|
Dynamic Range |
67.74dB |
|
|
A/D Converter |
12-bit on board, 8-bit R-G-B processed |
|
|
SN Ratio |
38.5dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Responsivity |
1.76V/lux-sec(550nm) |
|
|
Video Format & Max.Frame Rate |
14.5fps @2560 x 1922, 39fps @1280 x 960, 101fps @640 X 480 |
|
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
|
Output Rate |
96MBytes/s |
|
|
Exposure |
0.05ms~2s, ROI Auto & Manual |
|
|
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Color Rendering Technique |
Ultra Fine TM Color Engine |
|
|
Capture/Control API |
Native C/C++, .Net/C#, DirectShow, Twain |
|
|
Peak Quantum Efficiency |
N/A |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Recording System |
Still Picture and Movie |
|
|
Cooling System* |
Nature |
|
|
OPERATING ENVIRONMENT |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
|
Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory: 2GB or more |
||
|
USB port: USB3.0 High-speed Port |
||
|
Display: 17" or larger |
||
|
CD-ROM |
||
|
|
||
8.5 M pixel CMOS camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
CMOS sensor(Color) |
|
Scan Mode |
Progressive |
|
Max.Resolution |
3328 x 2548 (Approx. 8,500,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.3“ (6.44mm(H) x4.616mm(V), Diagonal7.923mm) |
|
Pixel Size |
1.67µm x 1.67µm |
|
Imaging Area |
6.44mm(H) x4.616mm(V) |
|
Dynamic Range |
0.31V/lux-sec(550nm) |
|
A/D Converter |
65.2dB |
|
SN Ratio |
12-bit on board, 8-bit R-G-B processed |
|
Spectral Range |
34dB |
|
Responsivity |
380-650nm (with IR-filter) |
|
Video Format & Max.Frame Rate |
8.3fps @3328 x 2548, 27fps @1664 x 1272 (Multiple Speed Level) |
|
Binning |
1 x 1, 2 x 2 |
|
Output Rate |
80MBytes/s |
|
Exposure |
0.1ms~2s, ROI Auto & Manual |
|
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Capture/Control API |
Native C/C++, .Net/C#, DirectShow, Twain |
|
Peak Quantum Efficiency |
N/A |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Recording System |
Still Picture and Movie |
|
Cooling System* |
Nature |
10 M pixel CMOS camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
MT9J003 CMOS (Color) |
|
|
Scan Mode |
Progressive |
|
|
Max.Resolution |
3584 x 2746 (Approx. 10,000,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/2.2“ (6.119mm(H) x4.589mm(V), Diagonal7.649mm) |
|
|
Pixel Size |
1.67µm x 1.67µm |
|
|
Imaging Area |
5.985mm(H) x4.585mm(V) |
|
|
Dynamic Range |
65.2dB |
|
|
A/D Converter |
12-bit on board, 8-bit R-G-B processed |
|
|
SN Ratio |
34dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Responsivity |
0.31V/lux-sec(550nm) |
|
|
Video Format & Max.Frame Rate |
7.2fps @3584 x 2746, 25fps @1792 x 1372 (Multiple Speed Level) |
|
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
|
Output Rate |
80MBytes/s |
|
|
Exposure |
0.1ms~2s, ROI Auto & Manual |
|
|
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
|
Capture/Control API |
Native C/C++, .Net/C#, DirectShow, Twain |
|
|
Peak Quantum Efficiency |
N/A |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Recording System |
Still Picture and Movie |
|
|
Cooling System* |
Nature |
|
|
OPERATING ENVIRONMENT |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
|
Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory: 2GB or more |
||
|
USB port: USB3.0 High-speed Port |
||
|
Display: 17" or larger |
||
|
CD-ROM |
||
14 M pixel CMOS camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
MT9F002 CMOS (Color) |
|
|
Scan Mode |
Progressive |
|
|
Max.Resolution |
4096 x 3286 (Approx. 13,500,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/2.3“ (6.138mm(H) x4.603mm(V), Diagonal7.672mm) |
|
|
Pixel Size |
1.40µm x 1.40µm |
|
|
Imaging Area |
5.734mm(H) x4.600mm(V) |
|
|
Dynamic Range |
65.3dB |
|
|
A/D Converter |
12-bit on board, 8-bit R-G-B processed |
|
|
SN Ratio |
35.5dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Responsivity |
0.724V/lux-sec(550nm) |
|
|
Video Format & Max.Frame Rate |
6.2fps @4096 x 3286, 21fps @2048 x 1644, 54fps @1024 x 822 |
|
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
|
Output Rate |
95.83MBytes/s |
|
|
Exposure |
0.1ms~2s, ROI Auto & Manual |
|
|
White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
|
Capture/Control API |
Native C/C++, .Net/C#, DirectShow, Twain |
|
|
Peak Quantum Efficiency |
N/A |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Recording System |
Still Picture and Movie |
|
|
Cooling System* |
Nature |
|
|
OPERATING ENVIRONMENT |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
|
Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory: 2GB or more |
||
|
USB port: USB3.0 High-speed Port |
||
|
Display: 17" or larger |
||
|
CD-ROM |
||
|
|
||
