MIC-M7 serials stereomicroscope

Product description:

Provide high-quality, durable and reliable optical system and operating mechanism. Range of accessories, diversified portfolio allocation. Meet the modern biology, medicine, scientific research, modern electronics industry online testing and other technology industries such as high-precision requirements.

Features:

1. A film coated with a special high-quality optical components, created a high-quality optical images

2. In a large field of view to form a flat surface and good contrast as positive, especially in the peripheral visual field more bright and clear image quality

3. A continuous zoom lens 0.7X ~ 4.5X (6.3:1), standard magnification 7X ~ 45X. (Optional auxiliary lens, Magnification 14X ~ 180X)

4. Effective standard working distance of100mm, optional auxiliary lens, working distance will be extended to26 mm~287mm, Create enough space for the use.

5. Observation head 45 ° inclined binocular diopter adjustable, to ensure that different vision users can get a clear image of satisfaction

6. Ergonomic design, the best eye point height, long time without feeling tired

7. Hand wheel zoom level (axial) bilateral setting, easy to operate and comfortable, zoom high repetition accuracy

8. With a variety of accessories, expand the application fields.



Technical Specifications

eyepiece

high eye point wide field eyepiece WF10X/20mm( can be mounted micrometer )

high eye point wide field eyepiece WF15X/15mm( can be mounted micrometer )

high eye point wide field eyepiece WF20X/10mm( can be mounted micrometer )

observation head

MIC-M7: binocular head, 45 ° inclined, continuous zoom lens 0.7X-4.5X, working distance100mm. interpupillary distance adjustment range of54mm-76mm, depending on the degree of bilateral adjustable ± 5

MIC-M7TR tee viewing head. 45 °inclined, 360 ° rotatable ; photographic camera can be equipped with the interface

MIC-M7V digital viewing head , built-in 3 million pixel CCD

auxiliary lens

0.5X/165mm. 1.5X/45mm. 2X/30mm.

focus brackets

A1 focus frames, focusing hand wheel adjustable elastic , lifting range50mm.

A3 industrial binding Focus Frame 2 ( industry-specific )

base

B2 Column transmission base , the upper and lower light source is a halogen lamp 12V15W ( adjustable brightness )

other external sources

ring light / LED light / cold light illumination

photography device

Photography connected tube ( with PK bayonet ), 3.2X photo eyepiece

imaging device

0.35X/0.5X/1.0XC type camera connected tube
