Standard Configuration
|
Model |
LY7001 |
|
Eyepiece |
Wide field WF10X(µ22mm) |
|
Objective |
Infinity plan achromatic objectives |
|
PL 4X/0.10 (Work distance)：19.8 mm |
|
|
PL 10X/0.25 (Work distance)：5.0 mm |
|
|
PLF L40X/0.85£¨spring£©(Work distance)：0.42mm(No magnification spherochromatic aberration ) |
|
|
PL 100X/1.25(Spring, oil) (Work distance)：0.36mm |
|
|
Eyepieces tube |
Trinocular, Inclination of 30˚. |
|
Epi-fluorescent illumination system |
Power supply unit, 110V or 220V can be selected. |
|
Mercury lamp is 100W/DC |
|
|
Turnplate Epi-fluorescence illuminator (UV.V.B.G filters system) |
|
|
Focus system |
Coaxial coarse/fine focus system, with tension adjustable and limit stopper, minimum division of fine focusing: 2μm. |
|
Nosepiece |
Quintuple(Backward ball bearing inner locating) |
|
Stage |
Double layer mechanical (Size:210mmX140mm,movingrange:75mmX50mm) |
|
Transmitted illumination system |
Abbe condenser NA.1.25 Rack & pinion adjustable |
|
Blue filter and Ground glass |
|
|
Collector for halogen lamp illumination and integrated field diaphragm |
|
|
6V 30W halogen lamp, adjustable brightness |
Optional accessories
|
Name |
Sort/Technique parameter |
NO. |
|
Eyepiece |
Dividing eyepiece(field number:µ22mm) 0.10mm/Div |
1122010 |
|
Objective |
Infinity plan achromatic objective PL 60X/0.80(Work distance)：0.46 mm |
2060160 |
|
Infinity plan achromatic fluorescent objective PL FL10X/0.35(Work distance)：2.37 mm |
2610110 |
|
|
Filter |
Green filter |
115002 |
|
Yellow filter |
115003 |
|
|
CCD adapter |
0.4X |
810001 |
|
0.5X |
810004 |
|
|
1X |
810002 |
|
|
0.5X with dividing0.1mm/Div |
810003 |
|
|
Camera |
DV-1 Video output(380/520 TV line) USB output(0.42 Mpixel) |
800001 |
|
DV-2 With USB output (1.3M,2.0M,3.0Mpixel) |
800003 |
|
|
DV-3 With video output(380/520 TV line) |
800005 |
|
|
Digital camera adapter |
CANON(EF) NIKON( F) |
820001 |
