Specification |
Model |
||||
|
MIC-F9 |
MIC-F9K |
MIC-F9M |
MIC-F9MB |
||
|
Viewing Head |
Monocular head,inclined at 45 °， 360° rota-table |
● |
● |
● |
● |
|
Eyepiece |
WF10 X 18mm |
● |
● |
● |
● |
|
Objective |
Achromatic： 4X ， 10X ， 40X(S) |
● |
● |
|
|
|
Achromatic： 4X ， 10X ， 40X(S)，100X (S) Oil |
|
|
● |
● |
|
|
Stage |
Plain stage with slide clips,Stage size：110mm X 120mm |
● |
● |
|
|
|
Mechanical stage Stage size：110mm x 120mm Moving range：60mm x 30mm |
|
|
● |
|
|
|
Double layers mechanical stage Stage size：110mm x 126mm Moving range：70mm x 30mm |
|
|
|
● |
|
|
Condenser |
0.65 Condenser with disc diaphragm |
● |
|
|
|
|
0.65 Condenser with disc diaphragm |
|
● |
|
|
|
|
N. A.1.25 Abbe Condenser with iris diaphragm and filter holder |
|
|
● |
● |
|
|
Focusing |
Coaxial coarse & fine focusing adjustment Fine focusing scale value 0.002mm |
● |
● |
● |
● |
|
Light Source |
LED1W,220V/110V |
● |
● |
● |
● |
|
Optional Accessory |
Eyepiece：WF16x,WF20x,P16x Objective：20X、60X(S) Semi-plan Objective：4X,10X,20X(S),40X(S),60X(S),100X(S)Oil Plan Objective：4X,10X,20X(S),40X(S),60X(S),100X(S)Oil Dual Viewing Head 1.3Mega、3.0Mega、5.0Mega、10.0Mega pixels COMS Digital camera eyepiece Photography attachment and CCD C-mount 0.5X、0.57X、0.75X |
||||
|
Specification |
Model |
|||
|
MIC-F9A |
MIC-F9B |
MIC-F9T |
||
|
Head |
Monocular head,inclined at 45 °， 360° rota-table |
● |
|
|
|
Compensation free binocular head,inclined at30°(48mm- 75mm) |
|
● |
|
|
|
Compensation free binocular head,inclined at30°(48mm- 75mm) |
|
|
● |
|
|
Eyepiece |
WF10×/18mm |
● |
● |
● |
|
Objective |
Achromatic 4×、10×、40×(s)、100×(s)Oil |
● |
● |
● |
|
Stage |
Double layer mechanical stage |
● |
● |
● |
|
Stage size：126mm×110mm |
● |
● |
● |
|
|
Moving Range：70mm×30mm |
● |
● |
● |
|
|
Condenser |
N.A.1.25 Abbe condenser with iris diaphragm & filter holder |
● |
● |
● |
|
Focusing |
Coaxial coarse & fine focusing adjustment,fine focusing scale value 0.002mm |
● |
● |
● |
|
Light Source |
LED1W,220V/110V |
● |
● |
● |
|
Optional Accessory |
Eyepiece：WF16×、WF20×、P16× Objective：20×（s）、60×(s) LED light Semi-plan objective：4×、10 ×、20×、40×(s)、60×(s)、100×(s)oil Plan objective：4×、10×、20×、40×(s)、60×(s)、100×(s)oil Dual viewing head Dark field and phase contrast attachment 1.3Mega、3.0Mega、5.0Mega、10.0Mega COMS digital camera eyepiece Photography attachment and CCD C-mount:0.5X、0.57X、0.75X |
|||
