UCIS Infinity Independent Achromatic Optical System
WF10x Plan Eyepieces,20mmField of View, High Eye Point up to21mm
Seidentopf Binocular/Trinocular Viewing Head, Inclined 30º, Rotatable 360º
Intermediate tube, with built-in focusable and centerable Bertrand lens, slider-type analyzer and compensator slot
Light Distribution: Binocular 100% or Binocular/Trinocular 20%/80%
52-75mmInterpupillary Distance Settings
±5 Diopter Adjustment
Quadruple Nosepiece Inward Facing with Positive Click Stops
Infinity “Strain-free” Achromatic 4x, 10x, 40x(S) and 100x (S/Oil) Objectives
Rotating Stage,156mmx138mm,MovementRange76mmx54mm
N.A. 1.25Polarizing Condenser
Different types of compensators: Full-wave plate, Quarter-wave plate, Wedge compensator
Coaxial Coarse and Fine Focus Mechanism with Markings on Fine Focus Knobs. Fine Focus Sensitivity0.001mm
6v 20w Halogen Illumination, 110-240V Wide Voltage
Dust Cover, Clear Blue Filter, Power Cord, Immersion Oil
Configuration:
|
Parts |
Specification |
Order No. |
MIC-P102i |
MIC-P103i |
|
MIC-P100i Frame |
MIC-P100i |
● |
● |
|
|
Observation Tube |
Binocular Tube, Interpupillary distance 52-75mm, 30°inclined. Diopter adjustment. |
MSP2 |
● |
|
|
Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined. Diopter adjustment. |
MTP2 |
|
● |
|
|
Eyepieces |
WF10X/20mm, High eye-point up to21mm. |
E1020PA |
●● |
●● |
|
WF10X/22mm, High eye-point up to21mm. |
E1022PC |
○○ |
○○ |
|
|
Plan Eyepieces, 16X/14mm. |
E1614PA |
○○ |
○○ |
|
|
Plan Polarizing Reticule Eyepiece10X/20mm. |
EP1020RA |
● |
● |
|
|
Objectives "Strain-free" Infinity Ach. |
4X |
WP-X4B |
● |
● |
|
10X |
WP-X10B |
● |
● |
|
|
40X(S) |
WP-X40B |
● |
● |
|
|
60X(S) |
WP-X60B |
○ |
○ |
|
|
100X(S)/(Oil) |
WP-X100B |
● |
● |
|
|
Objectives Infinity Plan Ach. |
2X |
WB-P2A |
○ |
○ |
|
4X |
WB-P4C |
○ |
○ |
|
|
10X |
WB-P10C |
○ |
○ |
|
|
20X(S) |
WB-P20C |
○ |
○ |
|
|
40X(S) |
WB-P40C |
○ |
○ |
|
|
60X(S) |
WB-P60C |
○ |
○ |
|
|
100X(S)/(Oil) |
WB-P100C |
○ |
○ |
|
|
Condenser |
Swing-out Condenser N.A.1.25 |
JG50A |
● |
● |
|
Stage |
360°Rotating Stage |
ZT7 |
● |
● |
|
Specimen Holder |
ZT7-2000 |
●● |
●● |
|
|
Attachable Mechanical Stage |
ZT7-3000 |
○ |
○ |
|
|
Nosepiece |
Quadruple Revolving Nosepiece |
ZQP480 |
● |
● |
|
Intermediate Tube |
PY10 |
● |
● |
|
|
Compensator |
1/4λ Retardation Plate |
PBS137 |
● |
● |
|
λ Tint Plate |
PBS530 |
● |
● |
|
|
Quartz Wedge |
PBSQ |
● |
● |
|
|
Kohler Illumination(With Field Diaphragm) |
KL3A |
● |
● |
|
|
Electrical Parts |
For 6V20W Halogen Lamp |
DQ2 |
● |
● |
|
For 6V30W Halogen |
DQ2A |
○ |
○ |
|
|
For 3W LED (With RechargeableBattery) |
DQLC2 |
○ |
○ |
|
|
For 3W LED |
DQL2B |
○ |
○ |
|
|
6V20W Halogen Bulb |
BZ-0022 |
●●● |
●●● |
|
|
6V20W Osram Halogen Bulb |
BZ-0022A |
● |
● |
|
|
6V30W Halogen Bulb |
BZ-0022B |
○○○ |
○○○ |
|
|
6V30W Osram Halogen Bulb |
BZ-0022C |
○ |
○ |
|
|
3W LED Bulb |
DQL2-1000 |
○ |
○ |
|
|
2200mAh LED RechargeableBattery |
UDCH-5300 |
○ |
○ |
|
|
250V/3.15AΦ5X20 Fuse |
BZ-0023 |
●●● |
●●● |
|
|
C-Mount |
0.5X |
SX2 |
|
● |
|
1X |
SX3 |
|
○ |
|
|
0.25X |
SX4 |
|
○ |
|
|
Filter |
Blue (Φ38 ) |
LA5-0011 |
● |
● |
|
Green (Φ38) |
LU5-0011 |
○ |
○ |
|
|
Yellow (Φ38) |
LH5-0011 |
○ |
○ |
|
|
Frosted Glass (Φ38) |
LB5-0011 |
○ |
○ |
|
|
Other |
Immersion Oil |
BZ-0027 |
● |
● |
|
Dust Cover |
BZ2-0014 |
● |
● |
|
|
Φ2mmAllen Screw Driver |
BZ2-0018 |
● |
● |
|
|
Φ1.5mmAllen Screw Driver |
BZ3-0018 |
●● |
●● |
|
|
Power Cord |
BZ-0021 |
● |
● |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
