Items |
Specifications |
MIC-M3 |
|
Eyepieces |
WF10×/Φ22 |
●● |
|
WF12.5×/Φ14 |
●● |
|
|
WF16×/Φ13 |
○○ |
|
|
Huygenian Eyepieces 5×/Φ20 |
○○ |
|
|
WF10×/Φ18 (Reticule,0.1mm) |
● |
|
|
Long Working Distance Plan Objectives |
○ |
|
|
LWD Plan 10×/0.25 |
● |
|
|
LWD Plan 20×/0.35 (S) |
● |
|
|
LWD Plan 40×/0.65 (S) |
● |
|
|
LWD Plan 100×/1.25 (S) (Oil) |
● |
|
|
Trinocular Head |
Inclined 45º, Light Distribution 20:80 |
● |
|
Nosepiece |
Qintuple |
● |
|
Mechanical Stage |
Size: 180×165mm, Travel Range: 50×40mm |
● |
|
Stage Plate |
1 (Φ10) |
● |
|
2 (Φ20) |
● |
|
|
3 (Φ40) |
○ |
|
|
Set of Stage Plate |
|
● |
|
Main Body |
|
● |
|
Polarizing Slide |
|
● |
|
Analyzing Slide |
|
● |
|
Illuminator |
6V/30W Halogen Lamp, Input voltage：100V～240V |
● |
|
Filters |
Blue, Green, Grey, White |
● |
|
1X C-mount |
Available for digital photo camera |
○ |
|
0.6X C-mount |
Available for digital camera |
○ |
|
Micrometer |
Division 0.01mm |
○ |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the
right to make design modification and changes without notice.
Packing Size: 660mm X 590mm X 480mm
Gross Weight: 20kgs Net Weight: 19 kgs
