DY-1 |
|
|
Optical System |
Infinite Optical System |
● |
|
|
Viewing Head |
Seidentopf Binocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary 48-75mm |
● |
|
|
Eyepiece |
Ф30 Wide Field Eyepiece WF10×/22, Eyepiece Tube Diameter30mm |
● |
|
|
Wide Field Eyepiece WF15×/16 |
○ |
||
|
Wide Field Eyepiece WF20×/12 |
○ |
||
|
Objective |
Infinite Plan Achromatic Objective 4×/0.10 WD=22 |
● |
|
|
LWD Infinite Plan Achromatic Phase Objective |
10×/0.25 WD=6 |
● |
|
|
20×/0.4 WD=3.1 |
● |
||
|
40×/0.55 WD=2.2 |
● |
||
|
Lamp House Adjustment Objective |
○ |
||
|
Nosepiece |
Backward Quintuple Nosepiece |
● |
|
|
Condenser |
ELWD Condenser NA0.3,LWD72mm(without Condenser150mm) |
● |
|
|
Centering Telescope |
Centering Telescope(φ30mm) |
● |
|
|
Phase Annulus |
10×、20×、40× Phase Annulus Plate(Adjustable) |
● |
|
|
|
Plain Stage 230×170 |
● |
|
|
Glasse Insert |
● |
||
|
Attachable Mechanical Stage,X、Y Coaxial Control,Moving Rang 80×120mm |
● |
||
|
Auxiliary Stage |
● |
||
|
Terasaki Holder |
● |
||
|
Petri Dish Holderφ38 |
|||
|
Petri Dish Holderφ54 |
● |
||
|
Focusing System |
Coaxial Coarse and Fine Adjustment, Fine Division0.002mm,MovingRangeup4.5mmdown4.5mm |
● |
|
|
Illumination |
6V30W Halogen Lamp, Brightness Adjustable |
● |
|
|
Filter |
Blue、Green and Ground Glasse,Diameter45mm |
● |
|
|
Accessories |
Photo Attachment |
○ |
|
|
C Mount 0.4× |
○ |
||
|
Epi-Fluorescent Attachment |
○ |
||
