Specification |
XSZ-N5A |
XSZ- N5B |
XSZ- N5T |
|
|
Viewing head |
Monocular Head.Inclined at 45° |
● |
|
|
|
Compensation Free Binocular Head .Inclined at 30° |
|
● |
|
|
|
Compensation Free Trinocular Head Inclined at 30° |
|
|
● |
|
|
Interpupillary Distance55mm-75mm |
|
● |
● |
|
|
Eyepiece |
WF10 × |
● |
● |
● |
|
Objective |
Achromatic objectives:4X,10X,40X(S),100X(S) Oil |
● |
● |
● |
|
Stage |
Double layers mechanical stage |
● |
● |
● |
|
Stage size:125mmX130mm |
● |
● |
● |
|
|
Moving range:75mm×50mm |
● |
● |
● |
|
|
Condenser |
Swing type N.A.1.25Abbe condenser with iris diaphragm & filter |
● |
● |
● |
|
Focusing |
Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
● |
|
Collector |
High brightness light collector |
● |
● |
● |
|
Light source |
Halogen bulb 6V/20W. AC85-230V |
● |
● |
● |
|
Adjustable brightness |
||||
|
Optional Accessory |
Eyepieces: WF16x,WF20x,P16x |
|||
|
Plan-Objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
||||
|
Semi-plan objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
||||
|
Photo and CCD attachment |
||||
