Main technology Specifications：
● Zoom objective magnification 0.58X~7.0X, zoom radio 12:1, working distance82mm(1X objective)
● Adjusting high lightness long life LED coaxial illumination
● The measurement to match between the support and the main body: φ45mm
● Standard CS-mount (the distance between the bearing surface and CCD plate is12.5mm)
● 0.4X, 0.5X, 0.67X、1X(standard outfits), 1.5X, 2X CCD adapters to be selected
● 0.3X, 0.5X, 0.75X, 1X(standard outfits), 1.5X, 2X、5X objective to be selected
● It can with Nikon,Olympus, Mitsutoyo standard screw thread endless far metallographic lens.
Standard specification：
|
TMM-670 |
TMM-670-D |
TMM-670C |
TMM-670C-D |
|
|
Main body ZDH0670 |
● |
|
|
|
|
Main body ZDH0670-D |
|
● |
|
|
|
Main body ZDH0670C |
|
|
● |
|
|
Main body ZDH0670C-D |
|
|
|
● |
|
Stand SD1-D |
● |
● |
● |
● |
|
LED illuminator MLC1000 |
|
|
● |
● |
TMM-670 series zoom monocular video microscope systems (main body) analyzed picture：
Main optical data:
|
Objective |
CCD adapter |
|||||||
|
0.4X |
0.5X |
0.67X |
1X |
1.5X |
2X |
|||
|
0.3X |
Optical magnification |
0.07X-0.84X |
0.09X-1.05X |
0.12X-1.4X |
0.17X-2.1X |
0.26X-3.15X |
0.35X-4.2X |
|
|
Field of video (mm) |
50X66.67-4.3X5.7 |
40X53.33- 3.43X4.57 |
30X40-2.57X3.43 |
21.1X28.2- 1.71X2.29 |
13.85X18.46- 1.14X1.52 |
10.3X13.71- 0.86X1.14 |
||
|
Working distance(mm) |
293 |
|||||||
|
0.5X |
Optical magnification |
0.12X-1.4X |
0.15X-1.75X |
0.2X-2.34X |
0.29X-3.5X |
0.44X-5.25X |
0.58X-7X |
|
|
Field of video (mm) |
30X40-2.57X3.43 |
24X32- 2.06X2.74 |
18X24-1.5X2 |
12.4X16.5- 1.03X1.37 |
8.2X10.91- 0.69X0.91 |
6.2X8.3- 0.51X0.69 |
||
|
Working distance(mm) |
175 |
|||||||
|
0.75X |
Optical magnification |
0.18X-2.1X |
0.225X-2.625X |
0.3X-3.5X |
0.44X-5.25X |
0.65X-7.875X |
0.87X-10.5X |
|
|
Field of video (mm) |
20X26.67-1.7X2.3 |
16X21.33-1.37 X1.83 |
12X16-1.03 X1.37 |
8.2X10.9- 0.69X0.91 |
5.53X7.38- 0.46X0.61 |
4.1X5.52- 0.34X0.46 |
||
|
Working distance(mm) |
117 |
|||||||
|
1X |
Optical magnification |
0.24X-2.8X |
0.3X-3.5X |
0.4X -4.69X
|
0.58X-7X |
0.87X -10.5X |
1.16X-14X |
|
|
Field of video (mm) |
15X20 -1.3X1.7 |
12X16 - 1.03X1.37 |
9X12 -0.77X1 |
6.2X8.3 - 0.51X0.69 |
4.1X5.52 - 0.34X0.46 |
3.1X4.1 - 0.26X0.34 |
||
|
Working distance(mm) |
82 |
|||||||
|
1.5X |
Optical magnification |
0.36X-4.2X |
0.45X -5.25X |
0.6X-7X |
0.87X-10.5X |
1.3X -15.75X |
1.7X-21X |
|
|
Field of video (mm) |
10X13.33-0.86X1.14 |
8X10.67- 0.69X0.91 |
6X8-0.5X0.7 |
4.13X5.52- 0.34X0.46 |
2.77X3.69- 0.23X0.3 |
2.1X2.82- 0.17X0.23 |
||
|
Working distance(mm) |
54 |
|||||||
|
2X |
Optical magnification |
0.48X-5.6X |
0.6X-7X |
0.8X-9.38X |
1.16X-14X |
1.7X-21X |
2.3X-28X |
|
|
Field of video (mm) |
7.5X10-0.64X0.86 |
6X8- 0.51X0.69 |
4.5X6 -0.38X0.51 |
3.1X4.1- 0.26X0.34 |
2.1X2.82- 0.17X0.23 |
1.57X2.09- 0.13X0.17 |
||
|
Working distance(mm) |
35 |
|||||||
|
5X |
Optical magnification |
1.2X-14X |
1.5X-17.5X |
2.0X-23.4X |
2.9X-35X |
4.4X-52.5X |
5.8X-70X |
|
|
Field of video (mm) |
3X4-0.26X0.345 |
2.4X3.2-0.21X0.27 |
1.8X2.4-0.15X0.2 |
1.24X1.66-0.1X0.14 |
0.82X1.09-0.07X0.15 |
0.62X0.83-0.05X0.07 |
||
|
Working distance(mm) |
10.1 |
|||||||
|
Magnification range of zoom body 0.58X-7X |
||||||||
|
Item/Model |
ZDH0670, ZDH0670C, ZDH0670-D, ZDH0670C-D |
|||||
|
Optical magnification |
0.6X~7.0X |
|||||
|
|
0.6X |
2.0X |
4.0X |
7.0X |
||
|
NA |
0.021 |
0.067 |
0.093 |
0.097 |
||
|
Depth of field |
3.2mm |
0.30mm |
0.11mm |
0.06mm |
||
|
Resolution |
16.0μm |
5.0μm |
3.6μm |
3.5μm |
||
|
TV distortion |
0.32% |
0.22% |
0.19% |
0.16% |
||
|
Install dimension |
0Φ45 mm-0.1 |
|||||
|
Fine adjustment (choose to buy) |
0~6mm |
|||||
|
The largest compatible camera |
1/2" |
|||||
|
CCD whorl mount |
1 inch 32 button |
|||||
The depth of field is the value of parsing images if you use 1/2" CCD camera and monitor of level 320 line.(Imaging surface concessional confusion circumference: 40μm)
Resolution is the theory resolution of wavelength in 550nm.
