Information
1. Sharp stereo erect image over a wide field of view
2.45°inclined and 360°rotatable binocular head with locked-in eyepiece. The left and right ocular-tube with diopter adjustment±5dp
3.Three kind of 90° 1×/2×,1×/3×,2×/4×,
Two kinds of objective rotation for selection: DTX11 are rotated by objective cover; DTX21 are rotated by knob
4. Power supply 110V/60HZ or 220V/50HZ
5. Product has CE approval
6. Illumination:L1.Upper reflected halogen light 12V 10W;down halogen light 12V 10W
7. Upper reflected halogen light 12V10W
8. Fluorescent tamp 5w for transmitted light and halogen lamp12v/10w for incident light
9. Fluorescent lamp 5W for transmitted light and halogen lamp 12v/10w for incident light. Brightness is adjustable
10. It always adopts led lights for the transmission and reflex illumination
11. Each packed in Styrofoam and in an inner box, Four sets in one canton
Technique data
|
Model |
Eyepiece |
Objective |
Up & down Mechanism |
Base/Working Stage |
|
DSM |
SWF10× |
1×-2× |
Arm curved style |
Ø95mmWhite/Black working stage Fan plain base |
|
DSM-W |
Arm curved style |
Ø95mmWhite/Black working stage Fan plain base |
||
|
Optional accessories WF5x、SWF10x、WF15x、WF20× Eyepiece；Ring light |
||||
Optical Data
|
Objective Magnification |
Eyepiece |
||||
|
WF5× |
SWF10× |
WF15× |
WF20× |
Working Distance (mm) |
|
|
Magnification Field of View (mm) |
Magnification Field of View (mm) |
Magnification Field of View (mm) |
Magnification Field of View (mm) |
||
|
1× |
5× 20.0 |
10× 22.0 |
15× 15.0 |
20× 10.0 |
100 |
|
2× |
10× 10.0 |
20× 11.0 |
30× 7.5 |
40× 6.5 |
|
|
1× |
5× 20.0 |
10× 22.0 |
15× 15.0 |
20× 70.0 |
100 |
|
3× |
15× 7.0 |
15× 7.3 |
45× 5.0 |
60× 4.3 |
|
|
2× |
10× 10.0 |
20× 11.0 |
30× 7.5 |
40× 6.5 |
100 |
|
4× |
20× 5.0 |
40× 5.5 |
60× 3.7 |
80× 3.2 |
|
