Information
1.Sharp stereo erect image over a wide
field of view
2.45°inclined and rotatable binocular head
3.The interpupillary distance is between55mm-75mm,The
left ocular-tube with diopter adjustment±5dp
4.Inside incident light,brightness adjustable,various illumination for
selection
5.Power supply 110V/60HZ or 220V/50HZ
6.product has CE approval.
Technique data
|
Model |
Eyepiece |
Objective |
Base/Working Stage |
Up & down Mechanism |
Incident illumination |
Transmitted illumination |
|
THL-BY |
HWF10× |
ZOOM0.75×-5× |
φ95 Frosted glass |
Pillar style |
Bowl halogen lamp 12V10W |
Halogen lamp 12V10W |
|
THL-BW |
HWF10× |
ZOOM0.75×-5× |
φ95 Frosted glass |
Arm curved |
Bowl halogen lamp 12V10W |
Halogen lamp 12V10W |
|
THL-BW-LED |
HWF10× |
ZOOM0.75×-5× |
φ95 Frosted glass |
Arm curved |
Bult-in LED ring light |
1WLED lamp |
|
THL-BP |
HWF10× |
ZOOM0.75×-5× |
φ120mmWhite/black |
Pillar style |
Natural illumination |
Natural illumination |
|
Optional accessories ：0.5×、1.5×、2× Auxiliary Objective；HWF5×、HWF10×、HWF20× Eyepiece；Ring light |
||||||
Optical Data
|
Eyepiece and objective |
Main body |
0.5xobjective |
0.5xobjective |
2x objective |
|
|
0.75x～5x |
0.375x～2.5x |
1.125x～7.5x |
1.5x～10x |
||
|
5x |
Total magnification |
3.75x～25x |
1.875x～12.5x |
5.625x～37.5x |
7.5x～50x |
|
Diameter of visual field |
Φ33～Φ5 |
Φ65～Φ10 |
Φ22～Φ3.3 |
Φ16～Φ2.5 |
|
|
10x |
Total magnification |
7.5x～50x |
3.75x～25x |
11.25x～75x |
15x～100x |
|
Diameter of visual field |
Φ33～Φ5 |
Φ65～Φ10 |
Φ22～Φ3.3 |
Φ16～Φ2.5 |
|
|
15x |
Total magnification |
11.25x～75x |
5.625x～37.5x |
16.875x～112.5x |
22.5x～150x |
|
Diameter of visual field |
Φ24～Φ4.2 |
Φ48～Φ8.5 |
Φ16～Φ2.8 |
Φ12～Φ2 |
|
|
20x |
Total magnification |
15x～100x |
7.5x～50x |
22.5x～150x |
30x～200x |
|
Diameter of visual field |
Φ20～Φ3.5 |
Φ40～Φ7 |
Φ13.3～Φ2.3 |
Φ10～Φ1.8 |
|
|
25x |
Total magnification |
18.75x～125x |
9.375x～62.5x |
28.125x～187.5x |
37.5x～255x |
|
Diameter of visual field |
Φ15.8～Φ2.4 |
Φ31.5～Φ4.8 |
Φ10.5～Φ1.6 |
Φ7.9～Φ1.2 |
|
|
|
working distance |
113mm |
220mm |
50mm |
35mm |
