Items

Specifications

O-I1

Eyepieces

WF10×/Φ18

●●

WF12.5×/Φ14

●●

WF16×/Φ13

○○

Huygenian Eyepieces 5×/Φ20

○○

WF10×/Φ18 (Reticule,0.1mm)

●

Plan Achromatic Objectives

Plan 4×/0.10

○

Plan 10×/0.25

●

Plan 20×/0.35 (S)

●

Plan 40×/0.65 (S)

●

Plan 100×/1.25 (S) (Oil)

●

Long Working Distance

Plan Objectives

PL L 40×/0.60

W.D=3.64mm

○

PL L 50×/0.70

W.D=3.01mm

○

PL L 80×/0.80(S)

W.D=1.08mm

○

Trinocular Head

Inclined 45º, Light Distribution 20:80

●

Nosepiece

Quadplex

●

Mechanical Stage

Size: 180×165mm,TravelRange: 50×40mm

●

Stage Plate

1 (Φ10)

●

2 (Φ20)

●

3 (Φ40)

○

Set of Stage Plate

●

Main Body

●

Polarizing Slide

●

Analyzing Slide

●

Illuminator

6V/30W Halogen Lamp, Input voltage：100V～240V

●

Filters

Blue, Green, Grey, White

●

1X C-mount

Available for digital photo camera

○

0.6X C-mount

Available for digital camera

○

Micrometer

Division0.01mm

○
