Features：
Excellent fluorescent image with infinitive optical system.
LED illumination with 50,000 hours life expectancy.
No need for cooling system and protection device due to LED cold light source.
465-475nm excited wavelength
Convenient to use, no need warm-up.
More fluorescent filters are available for different applications.
|
Specification |
XSP-YN8(LED) |
XSP-YN83(LED) |
|||||
|
Optical System |
Infinite optical system |
● |
● |
||||
|
Viewing Head |
Compensation free binocular head inclined at 30°, interpupillary 48-75mm |
|
● |
||||
|
Compensation free trinocular head inclined at 30°, interpupillary 48-75mm |
● |
|
|||||
|
Eyepiece |
Extra wide field eyepiece EW10X/22 |
● |
|
||||
|
WF10X/18 |
|
● |
|||||
|
Nosepiece |
Backward quintuple nosepiece |
● |
|
||||
|
Backward quadruple nosepiece |
|
● |
|||||
|
Infinite Objective |
Semi-plan Achromatic Objective |
4X, 10X, 40X, 100X |
|
● |
|||
|
20X |
|
○ |
|||||
|
Plan Achromatic Objective |
4X, 10X, 40X, 100X |
● |
|
||||
|
20X |
○ |
|
|||||
|
Fluorescent Objective |
4X, 10X, 20X, 40X, 100X |
○ |
○ |
||||
|
Condenser |
Swing condenser NA 0.9/0.25 |
● |
|
||||
|
Fixed NA 1.25 Condenser NA 1.25 |
|
● |
|||||
|
Focusing |
Coaxial coarse & fine adjustment, Fine division0.001mm |
● |
|
||||
|
Coaxial coarse & fine adjustment, Fine division0.002mm |
|
● |
|||||
|
Stage |
Double layers mechanical stage185X142/75X55 |
● |
|
||||
|
Double layers mechanical stage140X140/75X50 |
|
● |
|||||
|
Photo Attachment |
○ |
○ |
|||||
|
Video Adapter |
○ |
○ |
|||||
|
Illumination |
S-LED Illumination |
|
● |
||||
|
Halogen lamp 6V/20W |
|
○ |
|||||
|
Halogen lamp 6V/30W |
● |
|
|||||
|
Reflected Light Source |
|
Excitation |
Dichroic Mirror |
Barrier Filter
|
|
|
|
|
Blue Excitation |
BP460～490 |
DM505 |
BA515
|
● |
● |
||
|
Green Excitation |
BP510～550 |
DM570 |
BA590
|
○ |
○ |
||
|
Lamp |
3W LED (465-475nm) |
● |
● |
||||
|
3W LED (525-530nm) |
○ |
○ |
|||||
|
Immersion Oil |
Fluorescent free oil |
● |
● |
||||
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
