MIC-6 Comparison Microscope

Through optical magnifying, joint and superposition, analyze and compare two images of object field coverage which is observed by the same set of eyepieces to find minimum difference in microscopy and microscopy. It’s widely applied to distinguish minimum difference, such as bullet, tool mark, fingerprint, character or script and currency in the field of Public Security Bureau, Procuratorate, Court of Justice, Judicial Bureau, university, institute as well as electronics, agriculture, archeology, customs, bank.

Total magnification: 5.6x-127x

Eyepiece: WF10X  WF20X

Objective lens 0.7x-4.5x continuous variable objective lens.

Zooming ratio 1:6.5.additional 0.4x objective lens

Working distance: 100mm

Objective field coverage: φ2mm-φ60mm.observe l&r single field coverage, overlapping and cutting field coverage.

Moving scope of object stage: widthwise 54mm lengthwise 54mm vertical 54mm.

Horizontal moving scope of two stages: 54mm.scope of synchronous lift up and down 54mm.

Camera system: equipped with 3 million pixel HD digital camera.USB2.0 interface. resolution 1024x768.digital camera interface.

Illumination: high power LED light source. brightness or facula adjusted.

Power: IC 220V IN.DC 12V out. world safety standard.

Accessories for choice: digital camera, MIC criminal investigation image processing software, computer.
