MIC-30 series biological microscope with elaborate appearance and reliable quality, is beautiful and practical. Its easy operation and clear image inspire students' imagination and interesting of microscopy world, is helpful to explore the mystery of life science. New generation of scientists are born from here.
Compact and solid, innovative frame
High rigid but small as MIC-30 series is, specially designed for students. The frame with hollow design is lightweight but stable, easy to carry. Pure white body with blue on the both sides, is fresh and vivid.
Ergonomics design
According to different interpupillary distances and eyesights of different people, the spacing of binocular tubes can be adjustable from50mmto75mmand the left tube with the focusing device, diopter is ±5 adjustable.
Specifications
|
Optical system |
Finite color corrected optical system |
|
Viewing head |
30° inclined monocular head |
|
30° inclined binocular head, interpupillary distance: 50-75mm, ±5 diopter adjustable |
|
|
30° inclined trinocular head, splitting ratio R:T=80:20, interpupillary distance: 50-75mm, ±5 diopter adjustable |
|
|
30° inclined digital viewing head, built-in 3.0 mega pixels CMOS, USB output; interpupillary distance: 50-75mm, ±5 diopter adjustable |
|
|
Eyepiece |
Wide field plan eyepiece PL10X/18mmwith/without reticle; PL10X/18mmwith/without pointer |
|
Objective |
Achromatic objective( 4X, 10X, 40X, 100X) |
|
Plan achromatic objective( 4X, 10X, 40X, 100X) |
|
|
Nosepiece |
Quadruple nosepiece |
|
Frame |
Coaxial coarse and fine adjustment, with coarse adjustment stop and tightness adjustment, range:25mm, precision:0.002mm.3W LED, center presetting, intensity adjustable, external wide voltage AC adapter, 100V-240V_AC50/60Hz input, DC7.5V2Aoutput. |
|
Coaxial coarse and fine adjustment, with coarse adjustment stop and tightness adjustment, range:25mm, precision:0.002mm.3W LED, center presetting, intensity adjustable, external wide voltage AC adapter, 100V-240V_AC50/60Hz input, DC6V2Aoutput. |
|
|
Coaxial coarse and fine adjustment, with coarse adjustment stop and tightness adjustment, range:25mm, precision:0.002mm.3W LED, center presetting, intensity adjustable, internal switch 100V-240V_AC50/60Hz |
|
|
Coaxial coarse and fine adjustment, with coarse adjustment stop and tightness adjustment, range:25mm, precision:0.002mm.3W LED, center presetting, intensity adjustable, internal 4 pieces rechargeable batteries, external wide voltage battery charger, 100V-240V_AC50/60Hz input, DC6V1Aoutput. |
|
|
Stage |
132mmX140mmdouble layers mechanical stage, moving range: 50mmX76mm, precision:0.1mm. |
|
Condenser |
N.A.1.25Abbe condenser with iris diaphragm |
|
Others |
Filters for transmitted light: blue/yellow/green |
|
Camera accessories: 0.35X/0.5X/1X focusing C-mount |
