Excellent image quality with infinitive optical system.
Comfortable operating with ergonomic structure.
Better illumination with sliding-in centerable condenser, Convenient replacement with phase contrast and dark field condenser.
Features：
|
|
Extra Wide Field Eyepiece EW10X/20 with Diopter Adjustment as Optional |
|
|
Comfortable Observation with Eyepoint and interpupillary adjustable |
|
|
Sliding-in Centerable Condense Adjustable |
|
|
Handle for easy carrying |
|
|
Lamp Replacement by Direct Removing Housing |
|
Specification： |
XSP-Y3 |
|
|
Viewing Head |
Compensation Free binocular head, 30° inclined, Interpupillary 48-75mm |
● |
|
Compensation Free trinocular head, 30° inclined, Interpupillary 48-75mm |
○ |
|
|
Eyepiece |
Wide Field Eyepiece WF 10×/18 |
● |
|
Extra Wide Field Eyepiece EW10×/20 with Diopter Adjustment |
○ |
|
|
Objective |
Infinitive Semi-plan Achromatic Objectives 4×, 10×, 40×, 100× |
● |
|
Infinitive Plan Achromatic Objectives 4×, 10×, 40×, 100× |
○ |
|
|
Nosepiece |
Quadruple Nosepiece |
● |
|
Stage |
Double Layers Mechanical Stage140mm×140mm/ 75mm×50mm |
● |
|
Condenser |
Sliding-in centerable condenser NA1.25 |
● |
|
Focusing |
Coaxial Coarse & Fine Adjustment, Moving Range20mm |
● |
|
Illumination |
S-LED Illumination, Brightness Adjustable |
● |
|
6V/ 20W Halogen Lamp, Brightness Adjustable |
○ |
|
|
Phase Contrast Kit |
○ |
|
|
Dark Field Attachment |
○ |
|
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
