Specification

XSZ-N12A

XSZ-N12E

XSZ-N12D

XSZ-N12DE

Viewing Head

Sliding Binocular Head, Inclined at 45 (55mm-75mm)

●

●

Sliding Trinocular Head, Inclined at 45(55mm-75mm)

●

●

Eyepiece

WF10×/18mm

●

●

●

●

Objective

Achromatic 4×、10×、40×(s)、100×(s)Oil

●

●

●

Stage

Double layer mechanical stage

●

●

●

●

Stage Sixe:140mm140mm

Moving Range:75mm×50mm

Condenser

N.A.1.25Abbe condenser with iris diaphragm and filter

●

●

●

●

Focusing

Coaxial coarse & fine focusing adjustment in focusing scale value0.002mm

●

●

●

●

Light Source

Halogen bulb 6V20W or 6V15W, AC 220V/110V adjustable light intensity

●

●

●

●

Base Frame

Black decorating panel

●

●

Optional Accessory

Eyepiece：WF16×、WF20×、P16×

Objective：20×、60(s)、

Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil

Plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil

Reflective Mirror, Demonstration(Teaching) Head Dark field and Phase contrast device

1.3Mega、2.0Mega、3.0Mega、  5.0Mega pixels CMOS Digital camera eyepiece

Photography attachment and CCD Adapter 0.5×、0.57×、0.75×

LED illumination
