XDS-4B is MIC TECH’s new inverted microscope
· UCIS Infinity Independent Achromatic Optical System
· WF10x plan eyepieces, 22mm field of view, high eye point up
· Seidentopf binocular viewing head; inclined45º
· 48-75mm interpupillary distance settings ±5 Diopter adjustment
· Quintuple nosepiece inward facing with positive click stops
· Infinity long work distance plan Achromatic 10x, 20x, 40x and Infinity long work distance phase-contrast 20x objectives
· Right hand controls, low position, fixed stage, 240mm x 260mm, movement range 135mm x 85mm
· N.A. 0.30 Abbe condenser with iris diaphragm, with phase-contrast slide, long work distance 72mm.
· Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity 0.001mm
· 6 volt 30 watt halogen illumination
· Dust cover, power cord
|
Order No. |
Specification |
XDS-4B |
|
XDS-4B |
Microscope Frame |
● |
|
MS1A |
Trinocular Tube, Interpupillary distance 48-75mm,45°inclined,diopter adjustable. |
● |
|
E1022PC |
WF10X/22mm Plan Eyepiece, High eye-point diopter adjustable |
●● |
|
E1020RA |
WF10X/20mm Reticule Eyepiece, High eye-point up to 21mm |
○ |
|
DZ3 |
Centering Telescope |
● |
|
E1613PB |
16X/13mm Eyepiece |
○○ |
|
WB-P4C |
4X Infinity Long WD Plan Objectives |
○ |
|
WB-L10B |
10X Infinity Long WD Plan Objectives |
● |
|
WB-L20B |
20 X Infinity Long WD Plan Objectives |
● |
|
WB-L40B |
40X Infinity Long WD Plan Objectives |
● |
|
WB-L60B |
60 X Infinity Long WD Plan Objectives |
○ |
|
WB-LPHp10B |
10X Infinity Plan Phase-Contrast Positive Objectives |
○ |
|
WB-LPHp20B |
20X Infinity Plan Phase-Contrast Positive Objectives |
● |
|
WB-LPHp40B |
40X Infinity Plan Phase-Contrast Positive Objectives |
○ |
|
WB-LPHn10B |
10X Infinity Plan Phase-Contrast Negative Objectives |
○ |
|
WB-LPHn20B |
20X Infinity Plan Phase-Contrast Negative Objectives |
○ |
|
WB-LPHn40B |
40X Infinity Plan Phase-Contrast Negative Objectives |
○ |
|
DLST1 |
Multi-functional Semi-reflector |
● |
|
YGMKC-UV |
UV Fluorescence Filter(C) |
○ |
|
YGMKI-UV |
UV Fluorescence Filter(I) |
○ |
|
YGMKC-V |
V Fluorescence Filter(C) |
○ |
|
YGMKI-V |
V Fluorescence Filter(I) |
○ |
|
YGMKC-B |
B Fluorescence Filter(C) |
○ |
|
YGMKI-B |
B Fluorescence Filter(I) |
○ |
|
YGMKC-G |
G Fluorescence Filter(C) |
○ |
|
YGMKI-G |
G Fluorescence Filter(I) |
○ |
|
ZT1 |
Fixed Stage, 240mmX260mm; movement range: 135mmx85mm; with low-positioned X/Y coaxial control knob. |
● |
|
ZT1-1000 |
Drop specimen holder(φ118) |
● |
|
1D-0022 |
Specimen holder(125X85) |
○ |
|
1D-0021 |
Specimen holder(76X26, φ54) |
● |
|
ZT1A |
Mechanical Stage, 350mmx208mm; movement range: 50mmx50mm; with low-positioned X/Y coaxial control knob. |
○ |
|
ZQ580A |
Quintuple Revolving Nosepiece |
● |
|
SGJ1A |
Ultra long WD Condenser |
● |
|
PCB-LPHA |
Phase-contrast Slider |
● |
|
SGJ1-3000 |
6V30W Halogen Lamp House |
● |
|
SGJ5-0023 |
Filter Holder |
● |
|
LA1-0011 |
Blue filter(φ34) |
● |
|
LU1-0011 |
Green filter(φ34) |
● |
|
LH1-0011 |
Yellow filter(φ34) |
● |
|
SX1 |
0.5X C Mount |
● |
|
SX5 |
0.25X C Mount |
○ |
|
BZ-0022C |
6V30W Osram Halogen Bulb |
● |
|
BZ-0022H |
100W Mercury Lamp(China) |
○○ |
|
BZ-0022I |
100W Mercury Lamp(Osram) |
○ |
|
DX20A |
100W Mercury Lamp House |
○ |
|
DYX3 |
100W Power Supply Unit |
○ |
|
BZ-0023A |
250V/5A Φ5X20 Fuse |
●●● |
|
DYX1 |
Electrics for 6V30W Halogen |
● |
|
BZ-0023 |
250V/3.15A Φ5X20 Fuse |
●●● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved
the right to make design modification and changes without notice.
