MIC-VS series high-speed CCD industrial camera
CHARACTERISTIC
OF PRODUCTS:
1、Digital area CCD progressive scan
2、MIC -VS series high-speed CCD
industrial camera maximum resolution up to 640 x 480,1024 * 768,1280 * 960
pixels
3、Up to 60,30,15 frames / s.
4、IEEE1394ainterface; standard lens interface (CS C and I)
5、MIC-VS series of high-speed CCD
camera support from the industrial and external trigger flash interface
6、Controllable electronic shutter,
the overall exposure, without additional mechanical shutter
7、Development kits: VC SDK, DirectX,
Twain, VFW, LibView interface
8、Support for Windows 2000, XP and
Vista development process
SPECIFICATIONS AND PERFORMANCE LIST：
|
Model |
MIC-VS030FM/FC |
MIC-VS045FC/FM |
MIC-VS078FM/FC |
|
Frame Rate |
60fps |
50 fps |
30fps |
|
Phototonus |
Analog/Digital Converter: 10 Bit, Output: 8 Bit |
||
|
Dynamic Range |
Analog /Digital Converter: 9 Bit @25 °C, AGC 0 dB |
||
|
S/N Ratio |
9 Bit @25 °C, AGC 0 dB |
||
|
Type |
Progressive scan CCD |
||
|
Format |
1/3 " |
1/2 " |
1/3 " |
|
Resolution |
640x480 |
782X582 |
1024x768 |
|
Pixel Dimension |
5.6 μmx5.6 μm |
8.3 μmx8.3 μm |
4.65 μmx4.65 μm |
|
Lens Mount |
C/CS Mounting |
||
|
Shutter |
1/10000 to 30 s |
||
|
AGC |
0 to 36 dB |
||
|
Compensation |
0 to 511 |
||
|
Saturation |
0 to 200 % |
||
|
Whiter Balance |
-2 dB to +6 dB |
||
|
Dimension |
50.6x50.6x50 |
||
|
Weight、Power |
265 g、2.4W |
||
|
Max Temperature(Operation) |
-5 °C to45 °C |
||
|
Max Temperature(Storage) |
-20 °C to60 °C |
||
