0.3M pixel CCD camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX618ALA CCD (black white) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
640X480 (Approx. 300,000 Pixels) |
|
Sensor Size (Diagonal) |
1/4“ (Diagonal4.5mm) |
|
Pixel Size |
5.6µm x 5.6µm |
|
Imaging Area |
3.6mm(H) x2.7mm(V) |
|
G Sensitivity |
1200mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
72fps @640 x 480(Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Long Exposure |
0.056ms~40s, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
65% |
|
Readout Noise |
4.5 e (r.m.s) @ gain high /5.6 e (r.m.s) @ gain low |
|
Extinction Ratio |
1 : 2000 @1ms exposure time |
|
Smear |
-110dB |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
0.8M pixel CCD camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX204AK CCD ( color) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1024 x 768 (Approx. 800,000 Pixels) |
|
Sensor Size (Diagonal) |
1/3“ (Diagonal5.952mm) |
|
Pixel Size |
4.65µm x 4.65µm |
|
Imaging Area |
5.80mm(H) x4.92mm(V) |
|
G Sensitivity |
400mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
16fps @1024 x 768(Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Exposure |
0.16~4min, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
1.4Mpixel CCD camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX205AK CCD (color) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1360 x 1024 (Approx. 1,400,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2“ (Diagonal7.959mm) |
|
Pixel Size |
4.65µm x 4.65µm |
|
Imaging Area |
7.60mm(H) x6.20mm(V) |
|
G Sensitivity |
400mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
15fps @1360 x 1024(Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Exposure |
0.12~4min, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
1.45M pixel CCD camera black and white
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX285AK CCD (black white) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1360X1024 (Approx. 1400,000 Pixels) |
|
Sensor Size (Diagonal) |
2/3“ (Diagonal11mm) |
|
Pixel Size |
6.45µm x 6.45µm |
|
Imaging Area |
10.2mm(H) x8.3mm(V) |
|
G Sensitivity |
1240mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
15fps @1360 x 1024(Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Long Exposure |
0.126ms~4min, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
65% |
|
Readout Noise |
4.5 e (r.m.s) @ gain high /5.6 e (r.m.s) @ gain low |
|
Extinction Ratio |
1 : 2000 @1ms exposure time |
|
Smear |
< 0.002% |
|
Capture/Control AP |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
1.45M pixel CCD camera color
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX285AQ CCD (color) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1360X1024 (Approx. 1400,000 Pixels) |
|
Sensor Size (Diagonal) |
2/3“ (Diagonal11mm) |
|
Pixel Size |
6.45µm x 6.45µm |
|
Imaging Area |
10.2mm(H) x8.3mm(V) |
|
G Sensitivity |
1240mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
15fps @1360 x 1024(Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Long Exposure |
0.126ms~4min, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMII Color Engine |
|
Peak Quantum Efficiency |
65% |
|
Readout Noise |
4.5 e (r.m.s) @ gain high /5.6 e (r.m.s) @ gain low |
|
Extinction Ratio |
1 : 2000 @1ms exposure time |
|
Smear |
< 0.002% |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
2 M pixel CCD camera color
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX274AQ CCD ( color) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1600 x 1200 (Approx. 2,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/1.8“ (Diagonal8.923mm) |
|
Pixel Size |
4.40µm x 4.40µm |
|
Imaging Area |
8.50mm(H) x6.80mm(V) |
|
G Sensitivity |
420mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
10fps @1600 x 1200(Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Exposure |
0.17~240s, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
3 M pixel CCD camera color
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX252AQ CCD ( color ) |
|
Scan Mode |
Interlaced |
|
Max. Resolution |
2048 x 1536 (Approx. 3,100,000 Pixels) |
|
Sensor Size (Diagonal) |
1/1.8“ (Diagonal8.933mm) |
|
Pixel Size |
3.45µm x 3.45µm |
|
Imaging Area |
8.10mm(H) x6.64mm(V) |
|
G Sensitivity |
455mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit RG.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
6fps @2048 x 1536, 41fps @640 x 480 (Multiple Speed Level) |
|
Binning |
1 x 1,2 x 2 |
|
Exposure |
0.178ms~77.376ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
5 M pixel CCD camera color
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX282AQ CCD ( color) |
|
Scan Mode |
Interlaced |
|
Max. Resolution |
2560 x 1920(Approx. 4,900,000 Pixels) |
|
Sensor Size (Diagonal) |
2/3“ (Diagonal11mm) |
|
Pixel Size |
3.40µm x 3.40µm |
|
Imaging Area |
9.74mm(H) x7.96mm(V) |
|
G Sensitivity |
260mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
4.5fps @2560 x 1920, 9fps @1280 x 960 (Multiple Speed Level) |
|
Binning |
1 x 1, 2 x 2 |
|
Exposure |
0.203ms~104.899ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
5.1 M pixel CCD camera color
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX452AQ CCD (color) |
|
Scan Mode |
Interlaced |
|
Max. Resolution |
2592 x 1944 (Approx. 5,040,000 Pixels) |
|
Sensor Size (Diagonal) |
1/1.8“ (Diagonal9.04mm) |
|
Pixel Size |
2.775µm x 2.775µm |
|
Imaging Area |
8.23mm(H) x6.68mm(V) |
|
G Sensitivity |
260mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
4fps @2592 x 1944, 35fps @300 x 200 (Multiple Speed Level) |
|
Binning |
1 x 1, 2 x 2 |
|
Exposure |
0.212ms~77.503ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
5.2 M pixel CCD camera color
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX655AQ CCD (color) |
|
Scan Mode |
Progressive |
|
Max. Resolution |
2448 x 2050 (Approx. 5,018,000 Pixels) |
|
Sensor Size (Diagonal) |
2/3“ (Diagonal11.016mm) |
|
Pixel Size |
3.45µm x 3.45µm |
|
Imaging Area |
9.93mm(H) x8.70mm(V) |
|
G Sensitivity |
420mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
62dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
4.3fps @2448 x 2050, 10.5fps @960 x 720 (Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Exposure |
0.22ms~1min, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
60% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
