MIC-GZ USB2.0 CCD cameras include general grade and scientific grade. The CCD camera are all based on high performance SONY or KODAK CCD sensors. Thanks to less noise, wide dynamic range, high-definition, and excellent color production, MIC TECH CCD camera can help the users get high quality images.
Cooling function is optional for MIC-GZ01M(Sony ICX285), and MIC-GZ04M(Kodak KAI-4022). Employing thermal electronic cooler (TEC), it makes CCD noise less. MIC-GZ cooled CCD is ideal for dim light and fluorescence application. It is widely used in the Microscopic Fluorescence Imaging, Medical Testing (FISH), Solar Cell EL Inspection(NIR), Chemiluminescence, Industrial Fluorescence Detection(UV fluorescence), GEL Document, and other life scientific applications.
MIC-GZ serials general grade
|
Model |
Description |
|
MIC-GZ01C |
1.4 megapixel USB2.0 CCD Camera, Color |
|
MIC-GZ01M |
1.4 megapixel USB2.0 CCD Camera, Monochrome |
|
MIC-GZ08C |
8.0 megapixel USB2.0 CCD Camera, Color |
MIC-UC Series (Scientific Grade)
|
Model |
Description |
|
MIC-UC01C |
1.4 megapixel USB2.0 CCD Camera, Color |
|
MIC-UC01M |
1.4 megapixel USB2.0 CCD Camera, Monochrome |
|
MIC-UC04C |
4.0 megapixel USB2.0 CCD Camera, Color |
|
MIC-UC04M |
4.0 megapixel USB2.0 CCD Camera, Monochrome |
|
MIC-UC01C-COOL |
1.4 megapixel USB2.0 CCD Camera, Color, Cool |
|
MIC-UC01M-COOL |
1.4 megapixel USB2.0 CCD Camera, Monochrome, Cool |
|
MIC-UC04C-COOL |
4.0 megapixel USB2.0 CCD Camera, Monochrome, Cool |
|
MIC-UC04M-COOL |
4.0 megapixel USB2.0 CCD Camera, Monochrome, Cool |
|
MIC-UC01C 1.4 Mpix |
|
MIC-UC01C-Cool 1.4 Mpix |
|
|
Model |
GZ01C/M |
UC01C |
UC04C |
UC05C |
GZ08C |
|
Digital interface |
USB2.0 |
||||
|
Sensor type |
Progressive scan CCD |
||||
|
Resolution |
1360x1024 |
1360x1024 |
2048x2048 |
2592x1944 |
3264x2488 |
|
Sensor model |
Sony ICX205 |
Sony ICX285 |
Kodak KAI-4022 |
Sony ICX452 |
Sony ICX476 |
|
Sensor size |
1/2" |
2/3" |
4/3" |
1/1.8" |
1/1.8" |
|
Pixel size |
4.6μmx4.6μm |
6.45μmx6.45μm |
7.4μmx7.4μm |
3.45μmx3.45μm |
2.2μmx2.2μm |
|
Max. frame rate |
7.5fps@1360x1024 |
15fps@1360x1024 |
8fps@2048x2048 |
12fps@2592x1944 |
3fps@3264x2488 |
|
ADC |
12 bit |
14 bit |
14 bit |
12 bit |
12 bit |
|
Dynamic range |
43 dB |
74dB |
40.5dB |
63.5 dB |
50 dB |
|
Exposure time |
10us~60s |
10us~60min |
1us~20min |
42us~1000ms |
184us~435ms |
|
Read-out noise |
12e- |
8e- |
8e- |
7e- |
7e- |
|
Lens Mount |
C/CS mount |
||||
|
Color/Mono |
Color |
||||
|
IR cut filter |
integrated in C-mount18mmx18mm |
||||
|
Voltage supply |
USB 2.0 powered |
||||
|
Power consumption |
approx. 2W |
||||
|
Ambient condition |
0°C~60°C |
||||
|
Storage condition |
45~85% |
||||
|
Software |
MIC image analysis software |
||||
|
SDK |
available |
||||
|
Operation System |
Windows 2000/XP/Vista/wind 8 (32&64 bit) |
||||
|
Weight |
approx.240g |
||||
