3M pixel cmos camera

Sensor type

Color CMOS

Imaging sensor

size

1/2"

Pixel size

3.2μm×3.2μm

Effective pixels

2048x1536

Max resolution

2048x1536

Sensitivity

1.0V/lux-sec 550nm

Dynamic Range

>43dB

Exposure Controls

Automatic

Gain Control

Automatic

White Balance

One shot automatic control

Image Frame Rate

11fps @ 2048x1536

15fps @ 1024×768;

30fps @ 640×480.

Control interface

USB 2.0

Lens Mount

Standard C/CS-mount

Control Software Operating System

Windows XP,Vista, 7 (32 bit and 64 bit)

Power

USB 2.0 supported

Operating Temp

0 to50 °C

Dimensions

55mm×70mm×90mm

Weight

115g

Recommended PC Requirements

Pentium 4, 1.3 GHz or higher

512 MB RAM

200/500 MB hard drive free space or more

USB 2.0 Port

Windows XP,Vista, 7

Application

Education, Industrial microscopy, Live cell image, Medical, Semiconductor inspection, Metrology

Packing Contents

3.0MP Microscope Camera

1

USB 2.0 cable

1

CD with control software S-Viewer and driver

1

Camera User Manual

1

Optional accessories

Reducing lens 0.45X

Adapter ring (23.2mmto30mm)

Adapter ring (23.2mmto30.5mm)



5M pixel cmos camera

Sensor type

Color CMOS

Imaging sensor

size

1/2.5"

Pixel size

2.2μm×2.2μm

Effective pixels

2592x1944

Max resolution

2592x1944

Sensitivity

1.4V/lux-sec 550nm

Dynamic Range

41dB

Exposure Controls

Automatic

Gain Control

Automatic

White Balance

One shot automatic control

Image Frame Rate

6fps @ 2592x1944

15fps @ 1024×768;

30fps @ 640×480.

Control interface

USB 2.0

Lens Mount

Standard C/CS-mount

Control Software Operating System

Windows XP,Vista, 7 (32 bit and 64 bit)

Power

USB 2.0 supported

Operating Temp

0 to50 °C

Dimensions

55mm×70mm×90mm

Weight

115g

Recommended PC Requirements

Pentium 4, 1.3 GHz or higher

512 MB RAM

200/500 MB hard drive free space or more

USB 2.0 Port

Windows XP,Vista, 7

Application

Education, Industrial microscopy, Live cell image, Medical, Semiconductor inspection, Metrology

Packing Contents

5.0MP c-mount usb Microscope Camera

1

USB 2.0 cable

1

CD with control software S-Viewer and driver

1

Camera User Manual

1

Optional accessories

Reducing lens 0.45X

Adapter ring (23.2mmto30mm)

Adapter ring (23.2mmto30.5mm)


9M
pixel cmos camera

Sensor type

Color CMOS

Imaging sensor

size

1/2.3"CMOS

Pixel size

1.75μm×1.75μm

Effective pixels

3488x2616

Max resolution

3488x2616

Sensitivity

0.31V/lux-sec 550nm

Dynamic Range

39dB

Exposure Controls

Automatic

Gain Control

Automatic

White Balance

One shot automatic control

Image Frame Rate

2fps @ 3488×2616;

6fps @ 1600×1200;

20fps @ 1280×960;

30fps @ 800×600;

30fps @ 640×480.

Control interface

USB 2.0

Lens Mount

Standard C/CS-mount

Control Software Operating System

Windows XP,Vista, 7 (32 bit and 64 bit)

Power

USB 2.0 supported

Operating Temp

0 to50 °C

Dimensions

55mmx70mmx90mm

Weight

115g

Recommended PC Requirements

Pentium 4, 1.3 GHz or higher

512 MB RAM

200/500 MB hard drive free space or more

USB 2.0 Port

Windows XP,Vista, 7

Application

Education, Industrial microscopy, Live cell image, Medical, Semiconductor inspection, Metrology

Packing Contents

9.0MP Digital Microscope Camera

1

USB 2.0 cable

1

CD with control software S-Viewer and driver

1

Camera User Manual

1

Optional accessories

Reducing lens 0.45X

Adapter ring (23.2mmto30mm)

Adapter ring (23.2mmto30.5mm)
