MIC TECH GIGE CMOS cameras GD series is a newly developed product, with Gigabit Ethernet interface (high resolution, high speed, long distance transmission). GD series offers higher speed of the preview (up to 130fps@640x480). It is ideal for various applications in industry, especially in complex electromagnetic environment. The GD series support multi-camera synchronization, as well as online work without PC connection. It can be used in image processing and analysis by collaborating with the PLC (Programmable Logic Controller). SDK and source code of the Demo are available for secondary development
GD Series
|
Model |
Description |
|
GD03C |
3.0 megapixel GIGE camera, color |
|
GD05C |
5.0 megapixel GIGE camera, color |
|
GD10C |
10.0 megapixel GIGE camera, color |
|
GD14C |
14.0 megapixel GIGE camera, color |
|
Model |
GD03C |
GD05C |
GD10C |
GD14C |
|
|
Digital interface |
Gigabit Ethernet |
||||
|
Sensor Type |
Progressive scan CMOS |
||||
|
Resolution |
2048 x 1536 |
2592 x 1944 |
3664 x 2748 |
4384 x 3288 |
|
|
Sensor model |
MT9T001 |
MT9P001 |
MT9J001 |
MT9F001 |
|
|
Sensor size |
1/2" |
1/2.5" |
1/2.3" |
1/2.3" |
|
|
Pixel size |
3.2μm x 3.2μm |
2.2μm x 2.2μm |
1.67μm x 1.67μm |
1.4μm x 1.4μm |
|
|
Max. frame rate |
60fps@640x480 |
113fps@720x480 |
30fps@1280x960 |
13fps@1280x960 |
|
|
ADC |
10 bit |
12 bit |
10 bit |
12 bit |
|
|
Dynamic range |
43 dB |
41 dB |
>63 dBCell |
63.5 dB |
|
|
Exposure time |
6ms~650ms |
0.5ms~40min |
10μs~32ms |
1.6ms~17.9min |
|
|
Read-out noise |
12e- |
8e- |
8e- |
7e- |
|
|
ROI |
4 regions/frame |
||||
|
DSP frequency |
400MHz |
||||
|
On board memory |
256MB |
||||
|
I/O trigger |
programmable, 6 channels |
||||
|
Lens Mount |
C/CS mount |
||||
|
Color/Mono |
Color |
||||
|
IR cut filter |
integrated in C-mount18mmx18mm |
||||
|
Voltage supply |
USB 2.0 powered |
||||
|
Power consumption |
2.8W, 1.3W standby |
||||
|
Ambient condition |
-30°C~70°C |
||||
|
Storage condition |
-30°C~70°C |
||||
|
Software |
MIC |
||||
|
SDK |
available |
||||
|
Operation System |
Windows 2000/XP/Vista/7 (32&64 bit) |
||||
|
Weight |
Approx.265g(customizable housing case) |
||||
|
|
|||||
