Model XSZ-NSP Transmission Polarizing microscope is one of the most professional instruments, in common use, for Geological, Mineral, Metallurgical departments and relative Academy.
Recent years, with the development of optical technology, the Polarizing microscope is in widely use. Transmission Polarizing microscope is a very suitable product. The user can make single polarizing view, orthogonal polarizing view, cone light view and micro-photograph. The microscope is equipped with attachment, such as gypsum (1 λ),mica(1/4 λ ) test piece, quartz wedge and attachable mechanical stage. It is a novel microscope with maturity function and nicer quality


Specification

XSZ-NSP

Viewing head

Sliding Trinocular Head. Inclined at 45 °(50mm-75mm)

Eyepiece

WF10 × /18mm



10 × gridding eyepiece

10 × with reticule

WF10 × /22mm

Objective

Achromatic objective: 4 × ,10 × ,25 × , 40 ×  (S),63 × (S)

Stage

Round revolving stage

Stage dia: Φ160mm

Rotatable: 360 °

Condenser

Swing type N.A1.25 Abbe condenser with iris diaphragm & filter

Focusing

Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm

Collector

High brightness light collector

Light source

Halogen tungsten bulb 6V/30W.AC 85V-230V

Adjustable brightness

Optional Accessory

Eyepieces: WF16x,WF20x,P16x

1.3Mega3.0Mega Pixels CMOS Digital camera eyepiece
