Transmission polarizing microscope is a professional laboratory instrument which is the most commonly used in geology, minerals, metallurgy, material, etc, departments, and relative Universities and colleges. In recent years, with the advancing of optical technology, the polarizing microscope, as optical instrument, is to be used wider and wider, Transmission polarizing microscope is very suitable product which provides users to do single-polarized light observation, orthogonal polarizing observation, cone-ray observation and microscopic photography. It can also configure attachment like test piece of gypsum 1λ.mica1/4λ, quartz wedge and mechanical stage, It is a high quality novel instrument with more maturity functions.
|
Specification |
Model |
|
|
XSZ-N1P |
||
|
Viewing Head |
Compensation Free Trinocular Head Inclined at 30°(55mm-75mm) |
● |
|
Eyepiece |
10×Gridding Eyepiece |
● |
|
10×eyepiece with reticule |
● |
|
|
WF10×/22mm |
● |
|
|
Nosepiece |
Quintuple Nosepiece with centering adjustable |
● |
|
Objective |
Stress-free Infinity Plan Objectives:4×,10×,25×,40×(s),60 ×(s) Optional 63 ×(s) |
● |
|
Stage |
Rotary Stage |
● |
|
Stage Size：172mm |
||
|
Moving Range：360° |
||
|
Condenser |
Swing type N.A.1.25Abbe condenser with iris diaphragm |
● |
|
Testing Piece |
Gypsum 1λ testing piece |
● |
|
Mica 1/4λ |
● |
|
|
Quartz wedge testing piece |
● |
|
|
Focusing |
Coaxial coarse & fine focusing adjustment. With rack and pinion mechanism. Fine focusing scale value0.002mm |
● |
|
Illuminator |
High brightness fixed illumination |
● |
|
Light Source |
Halogen Bulb 6V/30W.AC85V230V |
● |
|
Adjustable Brightness |
||
|
Checking Tool |
0.01mm Micrometer |
● |
|
Optional Accessory |
Eyepiece: WF16×、WF20×、P16× |
|
|
1.3Mega、2.0Mega、3.0Mega、 |
||
|
5.0Mega Pixels CMOS Digital camera eyepiece |
||
|
Stress-free objestive:100×(s)Oil |
||
|
Photography attachment and CCD Adapter0.5×、×0.57×、0.75× |
||
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have
reserved the right to
make design modification and changes without notice.
