XSP-NYP3

XSP-NYP3/R

Viewing Head

Seidentopf binocular viewing head, Inclined at 30°

●

●

Seidentopf trinocular viewing head, Inclined at 30°

○

○

Eyepiece

Eyepiece WF10×/20 with scale of cross hair

●

●

Eyepiece WF10×/20 with reticule

●

●

WF10×/20

●

●

Infinite Strain Free

Plan Achromatic Objective

Objective 4×, 10× for Reflected/Transmitted system

●

●

Objective 20×, 40×, 60× for Transmitted system

●

●

Objective 20×, 40×, 60× for Reflected system

○

Nosepiece

Backward quadruple nosepiece, Center adjustable

●

●

Epi-Illuminator

12V/ 50W Halogen lamp with iris aperture diaphragm
and iris field diaphragm, Brightness adjustable

●

Analyzer

Rotatable analyzer with gradation 0°-360°

●

●

Bertrand Lens

Bertrand Lens, focus/center adjustable sliding
in/out of optical path

●

●

Optical Compensator

λ Slip（First class red）, 1/ 4λ Slip, Quartz wedge

●

●

Revolving Round Stage

Diameter Φ160mm, Graduated in 1° Increments,
Minimum resolution6’when using vernier scale

●

●

Condenser

NA0.9 Abbe condenser with Iris diaphragm & filter

●

●

Focusing

Coaxial coarse & fine adjustment, Range24mm,
 Fine division0.002mm

●

●

Polarizer

360° Rotatable

●

●

Illumination

12V/30W Halogen lamp, Brightness adjustable（Transmitted illumination）

●

●

Accessories

Photo Attachment

C Mount 0.4×

○

○

2×SLR Camera adaptor

○

○

Mechanical stage, Moving rang 30X40mm

●

●

Specimen presser

○

○

Micrometer

●

●

Filter

●

●

Filter (Blue)

○

○
