Polarizing microscope for normal inspection and education.
Widely used in crystallography, Geology, Analytical chemistry, Medicine, Biology,
Environmentallogy, Pharmacy,
Toxicology, Asbestos analysis and so on.
Single polarization, orthogonal polarization or conoscopic observation is ava1abIe.
Specification
|
|
|
XJN-P4 |
|
Viewing Head |
Sliding binocular viewing head, Inclined at 45° |
● |
|
Sliding trinocular viewing head, Inclined at 45° |
○ |
|
|
Eyepiece |
Eyepiece WF10×/18 with scale of cross hair |
● |
|
Eyepiece WF10×/18 with reticule |
● |
|
|
Eyepiece WF 10×/18 |
● |
|
|
Objective |
Strain free achromatic objective 4×、10×、25×、40×、63× |
● |
|
Strain free plan achromatic objective 25×、40×、63× |
● |
|
|
Lamp house adjustment objective |
○ |
|
|
Nosepiece |
Backward quadruple nosepiece, Center adjustable |
● |
|
Analyzer |
Rotatable analyzer with gradation 0°-90° |
● |
|
Bertrand Lens |
Bertrand lens, Sliding in/out of optical path |
● |
|
Optical Compensator |
λ Slip（first class red）, 1/ 4λ Slip, Quartz wedge |
● |
|
Revolving Round Stage |
Diameter Φ160mm, Graduated in 1° increments, Minimum resolution6’when using venire scale |
● |
|
Condenser |
NA1.25 Abbe condenser with iris diaphragm & filter |
● |
|
Focusing |
Coaxial coarse & fine adjustment, Range28mm, Fine division0.002mm |
● |
|
Polarizer |
360° Rotatable |
● |
|
Illumination |
12V/ 20W Halogen Lamp, Brightness Adjustable（Transmitted illumination） |
● |
|
12V/ 50W Halogen lamp, Brightness adjustable（Reflected illumination） |
● |
|
|
Accessories |
Mechanical stage, Moving rang 30×40mm |
● |
|
Specimen presser |
○ |
|
|
Micrometer |
● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
