Polarizing microscope for normal inspection and education.
Widely used in crystallography，Analytical chemistry，Medicine，Biology，environmentallogy，Pharmacy，Toxicology and so on．
Supply sharp and clear images by single polarization，orthogonal polarization or conoscopic observation.
Specification
|
|
|
XJN-P3 |
|
Viewing Head |
Sliding binocular viewing head, Inclined at 30° |
● |
|
Sliding trinocular viewing head, Inclined at 30° |
○ |
|
|
Eyepiece |
Eyepiece WF10×/18 with scale of cross hair |
● |
|
Eyepiece WF10×/18 with reticule |
● |
|
|
Eyepiece WF 10×/18 |
● |
|
|
Objective |
Strain free achromatic objective 4×、10×、25×、40×、63× |
● |
|
Lamp house adjustment objective |
○ |
|
|
Nosepiece |
Backward quadruple nosepiece, Center adjustable |
● |
|
Analyzer |
Rotatable analyzer with gradation 0°-90° |
● |
|
Bertrand Lens |
Bertrand lens, Sliding in/out of optical path |
● |
|
Optical Compensator |
λ Slip（First class red）, 1/ 4λ Slip, Quartz wedge |
● |
|
Revolving Round Stage |
Diameter Φ160mm, Graduated in 1° increments, Minimum resolution 6' when using venire scale |
● |
|
Condenser |
NA1.25 Abbe condenser with iris diaphragm & filter |
● |
|
Focusing |
Coaxial coarse & fine adjustment, Range28mm, Fine division0.002mm |
● |
|
Polarizer |
360° Rotatable |
● |
|
Illumination |
12V/ 20W Halogen lamp, Brightness adjustable（Transmitted illumination） |
● |
|
Accessories |
Mechanical stage, Moving range 30×40mm |
● |
|
Specimen presser |
○ |
|
|
Micrometer |
● |
|
|
Blue filter |
● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
