Description
Polarizing microscope for education．
Widely used in crystallography, Analytical chemistry, Medicine，Biology, Environmentallogy, Pharmacy, toxicology and so on.
Supply sharp and clear images．
Specification
|
|
|
XJN-P2 |
|
Eyepiece |
Eyepiece WF10×/18 with scale of cross hair |
● |
|
Eyepiece WF10×/18 with graticule |
● |
|
|
Eyepiece WF10×/18 |
● |
|
|
Eyepiece WF5×/20 |
● |
|
|
Objective |
Strain free achromatic objective 4×、10×、25×、40×、63× |
● |
|
Bertrand Lens |
Bertrand lens, Sliding in/out of optical path |
● |
|
Optical Compensator |
λ Slip（first class red）, 1/ 4λ Slip, Quartz wedge |
● |
|
Revolving Round Stage |
Diameter Φ130mm, Graduated in 1° increments, Minimum resolution 6' when using venire scale |
● |
|
Condenser |
NA1.25 Abbe condenser with iris diaphragm & filter |
● |
|
Polarizer |
360° Rotatable, Located on the top of collector |
● |
|
Illumination |
6V/ 20W Halogen lamp, Brightness adjustable（Transmitted illumination） |
● |
|
Accessories |
Micrometer0.01mm |
● |
|
Blue filter |
● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
