Comparison Microscope MIC-W14
By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences
Comparison microscope MIC-W14 is a new generation of product developed by our company by having accumulated many years of experiences, fully absorbed essences at home and abroad, this product successfully solved the technical problems of comparing ridge width and consistency adjustable (this technology is included in the national technology security projects) and the technical problem of binocular system inversion, so the main technical performance of the comparison microscope reached the international advanced level.
MIC-W14 is an upgraded product, which not only retains excellent technical performances of traditional products, but also increases its image quality and magnification, enlarges 10X and 20X eyepieces view field diameters, bridge body adopts with electronic lifting technology; and keeps linkage working stages, illumination and various accessories, and so on...inverted binocular observing system (located below the bridge body) makes the instrument shape, structure more beautiful, reasonable, reliable, more in line with ergonomic principles, and makes the instrument fully plays its functions of comparison and identification.
This product is an ideal instrument for public security, inspection, court on document retrieval, marks checking and school teaching (used for bullets, tool marks, fingerprints, seals, texts, coins comparison and identification), but also for industries and sectors such as banks, archaeology, electronics, biology, agriculture which need to identify on objects to use.
Accessories
|
WF10x/22mmeyepiece |
WF20x/14mmeyepiece |
|
150W cold light source |
Optical condenser |
|
Multi waves light source |
Objective lens: 1X, 1.5X, 2.5X, 4X, 6X |
|
Auxiliary objective lens: 0.5X, 10X |
Bullet holder |
|
Large working stages |
Frosted glass |
|
SLR camera interface |
CCD interface: 1.0x, 0.5X |
|
Electronic bullet spreader |
Crime Image software + decryption dog |
|
Polarized light |
Digital CCD (includes one USB data line) |
Technical Parameters of Comparison Microscope MIC-W14
|
Optical magnification range: 3X~200X (includes options) |
|
Eyepieces: WF10×/φ22 WF20×/φ12 (20X eyepiece for optional) |
|
Objective lens: 0.3X, 1X, 1.5X, 2X, 4X, 6X, 10X seven files |
|
Bridge body open file size:460mm |
|
IPD adjusting range: 60~75mm |
|
Working distance: 0.3X160mm, 10X49mm, the remaining objective lens100mm |
|
Objective stage dimension: 180X180mmmoving range: X/80mmY/80mmZ/55mm |
|
Horizontal linkage (manual) range:45mm |
|
Bridge body (electronic) lifting range:170mm |
|
Objective view field observing range: Φ1.2-Φ70mm(includes optional) |
|
2 kinds of light source: 24V300W optic fiber cold light source, with optic lens, brightness and light spots adjustable (unmarked in the picture), and adjustable white LED light source, tricolor LED light source; light source brightness high, good cooling effect, application range wide and easy to use, long service life. |
|
Power supply: 220V AC input, 24V and 4.5V~7.5V DC output, accords with international safety standard |
