Comparison Microscope MIC-W9

By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences



Comparison microscope MIC-W9 is a new generation of product developed by our company by having accumulated many years of experiences, fully absorbed essences at home and abroad, this product successfully solved the technical problems of comparing ridge width and consistency adjustable (this technology is included in the national technology security projects), so the main technical performance of the comparison microscope reached the international advanced level.



MIC-W9 is an upgraded product improved on MIC-W5B and MIC-W8 model, which not only retains excellent technical performances of MIC-W5B, but also increases its image quality and magnification, increases illumination ways and a variety of accessories, shape, structure more beautiful, reasonable, reliable, and makes the instrument fully plays its functions of comparison and identification.



This product is an ideal instrument for public security, inspection, court on document retrieval, marks checking and school teaching (used for bullets, tool marks, fingerprints, seals, texts, coins comparison and identification), but also for industries and sectors such as banks, archaeology, electronics, biology, agriculture which need to identify on objects to use.



Accessories:

Cold light source universal bracket

CCD camera

Photo block

Cold light source

Tilt working stage

Working stage

Horizontal working stage

Working stage knob

Tightening screw

Binocular head horizontal adjusting device

Bracket screw

Binocular head

Eyepieces

Cold light source lens





Technical Parameters of Comparison Microscope MIC-W9

Optical magnification range: 2.6X~80X

Eyepieces: 10X 20X

Objective lens: 0.64X, 1X, 1.6X, 12.5X, 4X (and 0.4X additional objective lens for optional)

Bridge body open file size:315mm

Binocular dip adjusting range: 0°~30°

Height of visual center of the pupil to the table:415mm

IPD adjusting range: 55~75mm

Working distance:100mm

Objective stage dimension: 100x100mmmoving range: X50mmY50mmZ55mm

Horizontal linkage range:45mm

Coarse lifting range:50mm

Objective view field observing range: Φ2.5-Φ69mm

Two kinds of light source: 24V150W optic fiber cold light source, with optical lens, brightness and light spot adjustable and 12V50W strong light illuminating

Power supply: 220V AC input, 12V, 24V DC output, accords with international safety standard.
