Comparison Microscope MIC-W7
By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences.
Features and Functions:
Digital comparison microscope MIC-W7 is an improved product based on original XZB-5B, makes the structure more reasonable, more fit ergonomics, vertical distance between pupillary center to desk top of original MIC-W5B is cut down 1/3, vertical distance between pupillary center to desk top of MIC-W7 is adjusted to425mm, hence users operate on general common desk top more convenient, without need specific working table.
Its design principles: observe images of left and right two objects through two eyepieces, so that making macro and micro comparison on two or more objects to achieve the purpose of identification.
Main Features:
|
Magnification range wide, from 7.68X~120X. |
|
Eye viewing is synchronized with video recording, convenient for multi persons observation. |
|
Using binocular observing system, can reduce operators’ eye fatigue. |
|
It has magnification correcting mechanism, with which can make magnification of left and right system extremely consistent. |
|
It can realize left and right single view field, cutting view field, overlapping view field. |
|
Equipped with digital camera, easy to use, and can configure other interfaces with general camera (for optional). |
|
It is quipped with 12V50W air-blast strong light source, brightness high, cooling effect good. |
|
It is equipped with 24V150W cold light source, with magnification optical lenses. |
|
Width and consistency of view field cutting ridge are adjustable. |
|
Digital comparison microscope MIC-W7 is an ideal instrument for public security, attorney, courts for documentation retrieval, trace inspection and their colleges for teaching ( on bullets, trace marks, footprints, seals, texts, coins identification and so on), also applied for identification sectors which need to make comparison such as banks, archeology, electronics, biology on objects and substances.
|
Accessories:
|
Air-blast strong light source |
Binocular cold light source |
|
B10X eyepieces |
16X eyepieces |
|
25X eyepieces |
Magnification correcting plates |
|
Red and green color filters |
Halogen bulbs |
|
Low magnification objective lens |
Coaxial light |
|
Bullet holder |
Screwdriver (3#) |
|
Polarizer, analyzer |
CCD camera |
|
Monitor |
|
Technical Parameters of Stereoscopic Microscope MIC-W7
|
Objectives magnification range: 0.7X~4.5X |
|
Interpupillary distance adjusting range: 55~75mm |
|
Round objective stage diameter: ￠95mm |
|
Hand wheel focusing range:60mm |
|
Lifting adjusting range:110mm |
|
Diopter adjusting range: +5 diopter |
|
Illumination: 110V or 220V input, oblique light illumination output 12V10W with a cup of halogen, transmitted light illumination 12V10W halogen, with camera interface |
