Information
1.Sharp
stereo erect image over a wide field of view.
2.45o inclined and 360o rotational binocular head with locked-in eyepiece. The
left ocular-tube with diopter adjustment ±5dp, The interpupillary distance is
between 55-75mm.
3.Three kinds of 90o rotational objet for seletion: 1X/2X,1X/3X,2X/4X
4.XTX-7(A,C)series supplied with pillar style stand; XTX-7(A,B,C)-W series
supplied with arm curved style stand.
5.Electric apparatus has CE approval
6.Power supply 110V/60Hz or 220V/50Hz
7.Each set packed in styrofoam and in an inner box. Four sets in one carton.
8.A wide range of optional accessories.
Optional accessories:
1.Eyepiece WF5X, WF10X, WF15X, WF20X
2.Objective 1X, 2X, 3X,4X,
3.Darkfield stage,Φ94.5mm
4.Jewel tweezer
5.White/black objcet plate,Φ60mm
6.Frosted glass object plate,Φ90mm
7.Incandescent bulb 12V/10W
8.Halogen bulb 12V/10W
9.LED
10.Ring fluorescent lighting 8W,10W
11.Wooden cabinet with lock and key/Aluminium case
|
MODEL |
EYEPIECE |
OBJECTIVE |
PLATE |
Illumination |
|
XTX-7A-W |
WF10X |
Rotated |
Frosted glass |
Natural illumination |
|
XTX-7C-W |
WF10X |
Frosted glass |
Incident illumination & transmitted illumination |
Optical data: M means magnification, V means visual field, W means Working distance (mm)
O means Objective Magnification
|
O |
Eyepiece |
W |
|||||||
|
5× |
10× |
15× |
20× |
|
|||||
|
M |
V |
M |
V |
M |
V |
M |
V |
|
|
|
1× |
5× |
20.0mm |
10× |
20.0mm |
15× |
15.0mm |
20× |
10.0mm |
76mm |
|
2× |
10× |
10.0mm |
20× |
10.0mm |
30× |
7.5mm |
40× |
6.5mm |
|
|
1× |
5× |
20.0mm |
10× |
20.0mm |
15× |
15.0mm |
20× |
10.0m |
76mm |
|
3× |
15× |
7.0mm |
30× |
6.7mm |
45× |
5.0mm |
60× |
4.3m |
|
|
2× |
10× |
10.0mm |
20× |
10.0mm |
30× |
7.5mm |
40× |
6.5m |
76mm |
|
4× |
20× |
5.0mm |
40× |
5.0mm |
60× |
3.7mm |
80× |
3.2m |
|
