1. Incident reflected halogen lamp 12V10W;
Transmitted halogen lamp 12V10W.
2. Incident reflected halogen lamp 12V10W; Transmitted
halogen lamp 12V10W; Brightness is adjustable.
3. Halogen lamp 12V/10W for incident lamp and fluorescent lamp 5W for transmitted
lamp.
4. Halogen lamp 12V/10W for incident lamp and fluorescent lamp 5W for
transmitted lamp. Brightness is adjustable.
5. Both incident and transmitted light with LED.
Optical data
|
Eyepiece |
Objective |
Standard Objective |
Auxiliary Objective |
||
|
|
|
0.75X~5X |
0.5X |
1.5X |
2.0X |
|
HWF5X |
Total magnification |
3.75X~25X |
1.875X~12.5X |
5.625X~37.5X |
7.5X~50X |
|
Field of View |
Ø 31~Ø 4.6 |
Ø 61.3~Ø 9.2 |
Ø 22~Ø 3.3 |
Ø 16~Ø 2.5 |
|
|
HWF10X |
Total magnification |
7.5X~50X |
3.75X~25X |
11.25X~75X |
15X~100X |
|
Field of View |
Ø 33~Ø 5 |
Ø 65~Ø 10 |
Ø 22~Ø 3.3 |
Ø 16~Ø 2.5 |
|
|
HWF15X |
Total magnification |
11.25X~75X |
5.625X~37.5X |
16.875X~112.5X |
22.5X~150X |
|
Field of View |
Ø 24~Ø 4.2 |
Ø 48~Ø 8.5 |
Ø 16~Ø 2.8 |
Ø 12~Ø 2 |
|
|
HWF20X |
Total magnification |
15X~100X |
7.5X~50X |
22.5X~150X |
30X~200X |
|
Field of View |
Ø 20~Ø 3.5 |
Ø 40~Ø 7 |
Ø 13.3~Ø 2.3 |
Ø 10~Ø 1.8 |
|
|
HWF25X |
Total magnification |
18.75X~125X |
9.375X~62.5X |
28.125X~187.5X |
37.5X~255X |
|
Field of View |
Ø 15.8~Ø 2.4 |
Ø 31.5~Ø 4.8 |
Ø 10.5~Ø 1.6 |
Ø 7.9~Ø 1.2 |
|
|
|
Working distance |
113mm |
220mm |
50mm |
35mm |
