Exported well all over the world because of their price to performance value, the TGT-L Series is a customer favorite. The fixed transmission system combines with a unique zoom design to deliver a 1:7 zoom ratio. Easy operation, long working distance, clear resolved image and beautiful appearance are characteristics of the TGT-L series. Overall the MIC Series is robust and problem free, and rates among the best stereo microscopes in the world. These microscopes are used extensively world wide in medical research and health care, biology and botany research, and agriculture, as well as in electronic component manufacturing. They are also particularly well suited for the inspection and production of LC Polymer films, exposed liquid crystals in LC circuits and glass substrates, LCD printing pastes, LED production, fabric and fiber evaluation, electronics assembly, printed circuit board manufacturing, medical device inspection and all types of quality control environments.
Standard configurations
|
Zoom ratio |
1:7 |
|
Objective zoom range |
0.65X-4.5X |
|
Eyepiece |
10X eyepiece |
|
Working distance |
95mm |
|
Interpupillary distance adjustment range |
55mm-75mm |
|
Binocular head |
inclination of 45 |
|
Diopter adjustment |
±5 diopter |
|
Optical body rotation |
360 |
|
Voltage input |
110V/60HZ or 220V/50HZ |
|
Top halogen lamp |
6V12W adjustable brightness |
|
Bottom fluorescent lamp |
5W |
Technical data: M means magnification, V means visual field, W means Working distance(mm)
A means Auxiliary Objective
|
A |
Eyepiece |
W |
|||||||
|
WF10X |
WFl5X |
WF20X |
WF25X |
|
|||||
|
M |
V |
M |
V |
M |
V |
M |
V |
|
|
|
0.5X |
3.3X-22.5X |
61.4-8.8 |
4.9X-33.8X |
49.2-7 |
6.5X-45X |
40-5.8 |
8.1X-56.3X |
37-5.2 |
150 |
|
0.75X |
4.9X-33.8X |
41-5.9 |
7.3X-50.6X |
32.8-4.7 |
9.75X-67.5X |
26.6-3.8 |
12.2X-84.4X |
24.6-3.5 |
100 |
|
1X |
6.5X-45X |
30.7-4.4 |
9.8X-67.5X |
24.6-3.5 |
13X-90X |
20-2.9 |
16.3X-112.5X |
18.5-2.6 |
95 |
|
1.5X |
9.8X-67.5X |
20.5-2.9 |
14.6X-101.3X |
16.4-2.3 |
19.5X-135X |
13.3-1.9 |
22.4X-168.8X |
12.3-1.8 |
41 |
|
2X |
13X-90X |
15.4-2.2 |
19.5X-135X |
12.3-1.8 |
26X-180X |
10-1.4 |
32.5X-225X |
9.2-1.3 |
26 |
|
|
|||||||||
|
|
|||||||||
