Innovative structural design, more compact and flexible, more comfortable, more widely used. |
|
Large zoom ratio, high resolution, clear and wider |
|
Full-featured, cost-effective, modern electronics industry is now testing and equipment matching of choice. |
|
High-quality optical system coated with a special coating of optical components, creating a high-quality optical system. |
|
Standard Magnification 7X ~ 45X; optional auxiliary lens, 3.5X ~ 180X magnification |
|
Effective working distance long enough space to use to create |
|
Ergonomic design, long time without feeling tired convenient and comfortable |
Technical Specifications
|
eyepiece |
high eye point wide field eyepiece WF10X/20mm, WF15X/15mm, WF20X/10mm( can be mounted micrometer ) |
|
high eye point wide field eyepiece diopter adjustable WF10X/20mm, WF15X/15mm, WF20X/10mm( can be mounted micrometer ) |
|
|
observation head |
SZM45N binocular head . 45 ° tilt , 360 ° rotation ; 0.70X ~ 4.5X continuous zoom lens . Long working distance100mm. Interpupillary distance adjustment range 54-75mm; two eyepieces diopter can be adjusted to regulate the range of ± 5 |
|
SZM45TRN tee viewing head . 45 ° tilt , 360 ° rotation ; photographic camera can be equipped with the interface ; 0.70X ~ 4.5X continuous zoom lens . Long working distance100mm. Interpupillary distance adjustment range 54-75mm; two eyepieces diopter can be adjusted to regulate the range of ± 5 |
|
|
auxiliary lens |
0.5X/165mm. 1.5X/45mm. 2X/30mm. |
|
focus brackets |
A1 focus frames, focusing hand wheel adjustable elastic , lifting range50mm. |
|
A3 industrial binding Focus Frame ( industry-specific ) |
|
|
base |
2L stand arm -in LED base, the upper and lower LED lighting , independent switch , adjustable brightness , low security , low power consumption , low heat , long life. |
|
B1 Column small flat base |
|
|
B2 Column transmission base , the upper and lower light source is a halogen lamp 12V15W ( adjustable brightness ), (7W fluorescent optional ) |
|
|
B3 Column large flat base |
|
|
B5 vertical arm large flat base |
|
|
B6 Column oblique flat base |
|
|
J1 Column fan base |
|
|
J2 arm stand fan base |
|
|
J3Lstand arm -in LED light base, the upper and lower LED lighting , independent switch , adjustable brightness , low security , low power consumption , low heat , long life. |
|
|
J4Lstand arm -in LED light base, the upper and lower LED lighting , independent switch , adjustable brightness , low security , low power consumption , low heat , long life. |
|
|
STL1 arm Column Stand |
|
|
STL2 arms Column Stand |
|
|
|
ring light / LED light / fiber optic lighting |
|
other external sources |
variety of other base, ring lights , fluorescent lights, fiber optic lighting, etc. can be the first |
|
other optional |
mobile platform |
