MIC-DN45 continuous zoom monocular video microscope series

Parallel optical system, clear imaging, widely used in modern production in the field of machine vision, industrial inspection fields, science research applications.

Compact design, so that all functions are concentrated in a barrel, and is very suitable for modern design, Prepared in a small installation space.

Parallel optical imaging system, and the application of advanced multi-layer coating technology, good fix the edge of the field of view of the imaging results, to get high-resolution, high-contrast images, since then restore the true color of the object observed.

Resolution 63-180lp/mm, to meet the requirements of conventional imaging machine vision.

may need to select a variety of auxiliary magnification lens and CCD adapters, making the whole system has a maximum

Magnification range up to 0.35X-18X, working distance37mm-356mm, object field range0.23mm-91mm.

Technical Specifications

Continuous zoom lens 0.7-4.5X, zoom ratio 6.4:1

Standard working distance of100mm

Eyepiece: 0.5X (optional 0.35X/1X/2X)

Objective 1X (optional 0.5X, 2X)

Primary mirror body and the bracket with the size φ39.6mmand φ50mm

Focusing hand wheel adjustable elastic, focusing range63mmand50mm

Main standard diameter: φ25mm, height 323/270mm

Optional various base

Technical parameters

objective

Project

CCD eyepiece

0.35X

0.5X

1X

2X

0.5X

optical magnification

0.1225 - 0.7875

0.175 - 1.125

0.35 - 2.25

0.5 - 4.5

market coverage

46 - 7

35 - 5

17.6 - 3

8.8 - 1.3

Working Distance

198

1X

optical magnification

0.245 - 1.575

0.35 - 2.25

0.7 - 4.5

1.4 - 9

market coverage

23 - 3

17.6 - 2.7

9 - 16

4 - 0.7

Working Distance

96

2X

optical magnification

0.49 - 3.15

0.7 - 4.5

1.4 - 9

2.8 - 18

market coverage

11.6 - 1.7

8.8 - 1.3

4 - 0.71

2 `- 0.3

Working Distance

46
