Specification

Model

J-M1J

J-M1JT

J-M1JA

J-M1JAT

Viewing head

Compensation Free Binocular Head. Inclined  at 45 ° (50mm-75mm)

●

●

Compensation Free Trinocular Head.  Inclined at 45 ° (50mm-75mm)

●

●

Eyepiece

  WF10 × /20mm

●

●

  WF10 ×/22mm

●

●

  WF10 × /20mmwith reticule0.1mm

●

●

●

●

Nosepiece

  Quadruple nosepiece

●

●

  Quintuple nosepiece

●

●

Objective

  195 metallurgical

  objectives

4 × /0.1W.D.25mm

●

●

10 ×/ 0.25W.D.11mm

20 × /0.4W.D.9mm

40 × /0.6W.D.3.8mm

  Infinity metallurgical

  objectives

4 × /0.1W.D.25mm

●

●

10 ×/ 0.25W.D.12mm

20 × /0.4W.D.10mm

40 × /0.6W.D.7.1mm

  50 × /0.75W.D.1.9mm80 (S)× /0.9W.D.0.9mm

○

○

○

○

Stage

  Double layers mechanical stage

●

●

●

●

  Stage size:242mm×172mm

  Central stage: Φ110mm

  Moving range:75mm×50mm

Focusing

  Coaxial coarse & fine focusing adjustment  with

  rack and pinion mechanism Fine focusing scale

  Value0.002mm

●

●

●

●

Illumination

  Epi-Kohler illumination. With aperture

  iris diaphragm and field iris diaphragm.

  12V/30W.AC85V-230V Adjustable brightness

●

●

●

●

Filter

  Blue, green, yellow

●

●

●

●

Polarizing outfit

  Analyzer rotatable 360 ° ,polarizer & Analyzer

  can be slided slided in / out of the optical path

●

●

●

●

Checking tool

 0.01mmmicrometer

●

●

●

●

Optional Accessory

  1.3、2.0、3.0、5.0 Mega pixels CMOS electronic eyepiece

  Photography attachmrnt
