Biggest horizontal optical metallurgical
microscope.
Widely used in researching microstructure of metal. Viewing, projection, photography
in bright field, dark field or polarization.
Can be used in research unit, metallurgical factory and colleges of industry for metallurgical testing, like metallographic and heat treatment, metal physics, process of steel making and casting.
Specification
|
|
|
NY-4 |
|
Eyepiece |
8×/18 |
● |
|
10×/16 |
● |
|
|
Eyepiece with scale of cross hair 10× |
● |
|
|
12.5×/14 |
● |
|
|
16×/12 |
● |
|
|
Plan Achromatic Objective |
4×/0.10 WD52.3mm |
● |
|
10×/0.20 WD17.3mm |
● |
|
|
25×/0.40 WD0.90mm |
● |
|
|
40×/0.65 WD0.40mm |
● |
|
|
63×/0.85 WD0.20mm |
● |
|
|
100×/1.25 WD0.30mm |
● |
|
|
Adapter for Dark Field |
Adapter for objective 10× |
● |
|
Adapter for objective 25× |
● |
|
|
Viewing Head |
Sliding binocular viewing head |
● |
|
Kohler Incident Light |
12V/50W Halogen light, Center and brightness adjustable |
● |
|
Xenon lamp, Center and brightness adjustable |
● |
|
|
Polarizer and analyzer |
● |
|
|
Stage |
Cycle-mechanical stage Φ160mm, Center adjustable moving range12×16mm |
● |
|
Stage: Φ10, Φ13, Φ15, Φ20, Φ21, Φ27 |
● |
|
|
Accessories |
Photo/Video attachment |
○ |
|
0.01mm Micrometer scale0.01mm |
● |
|
|
Negative Eyepiece |
F33 F44.3 |
● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
